Outback Spectrum User Manual

Assembly Instructions
Install one side shelf
12
between left front leg
13
and left rear leg
14
using
M6x25 bolts
D
.
Install the other side shelf
12
between right front
leg
15
and right rear leg
16
using M6x25 bolts
D
.
Step 4
Step 3
b:
a:
11
a: Unscrew the locknuts
from the axle
20
and
remove the axles
washers.
b: Slide the axle
20
through left front leg
13
, trolley base
17
and left
rear leg
14
. Place axle
washers on each end
of the axle. Slide the
wheels
18
over each
end of the axle. Secure
the wheels into place
with the locknuts. Place
the hubcaps
19
onto the
outsides of the wheels.
20
20
13
14
17
18
18
19
12
19
D
D
D
D
12
13 14 15 16

Outback Spectrum Specifications

General

Burner Material	Stainless Steel
Number of Burners	4
Warming Rack	Yes
Side Burner	Yes
Ignition Type	Electronic
Fuel Type	Propane
Type	Gas
BTU Output	48, 000 BTU
Grill Material	Stainless Steel
