OVE PASADENA - Annex Imperial Measurements (Inches)

P. 32
ANNEX IMPERIAL MEASUREMENTS (INCHES)
ANNEXE MESURES IMPÉRIALES (POUCES)
ANEXO MEDIDAS IMPERIALES (PULGADAS)
Note: The * character in the Conguration ID can be replaced by any alphanumerical character. It can be skipped while matching your ID to this table.
Note: Le charactère * dans le Conguration ID peut être remplacé par n’importe quel caractère alphanumérique. Il peut être ignoré en cherchant le ID corresponsant dans la table.
Nota: El carácter * en la Conguration ID se puede reemplazar por cualquier carácter alfanumérico. Puede ignorarse buscando el ID correspondiente en la tabla.
CONFIG
ID
DP IP SP BASE
W
MIN
W
MAX
D H H2 A B C
E
MIN
E
MAX
O P X Y
PA0531*I* DPC25 (25 6/16in) IP10 (9 10/16in) SP29 (28 15/16in) 40x32x2 12/16in 37 12/16 38 8/16 32 74 12/16 72 32 31 2/16 39 13/16 38 15/16 N/A 25 13/16 13 12/16 37 12/16 29 13/16
PA0531*0* DPC25 (25 6/16in) IP10 (9 10/16in) SP29 (28 15/16in) 37 12/16 38 8/16 30 8/16 72 72 31 7/16 30 8/16 N/A 38 2/16 N/A 25 13/16 13 12/16 37 12/16 29 13/16
PA0532*0* DPC25 (25 6/16in) IP10 (9 10/16in) SP31 (30 15/16in) 37 12/16 38 8/16 32 8/16 72 72 33 7/16 32 8/16 N/A 38 2/16 N/A 25 13/16 13 12/16 37 12/16 31 14/16
PA0533*D* DPC25 (25 6/16in) IP10 (9 10/16in) SP33 (32 15/16in) 40x36x2 12/16in 37 12/16 38 8/16 36 74 12/16 72 36 35 1/16 39 13/16 38 15/16 N/A 25 13/16 13 12/16 37 12/16 33 13/16
PA0533*0* DPC25 (25 6/16in) IP10 (9 10/16in) SP33 (32 15/16in) 37 12/16 38 8/16 34 8/16 72 72 35 6/16 34 8/16 N/A 38 2/16 N/A 25 13/16 13 12/16 37 12/16 33 13/16
PA0541*0* DPC25 (25 6/16in) IP12 (11 10/16in) SP29 (28 15/16in) 39 12/16 40 8/16 30 8/16 72 72 31 7/16 30 8/16 N/A 40 2/16 N/A 25 13/16 13 12/16 39 12/16 29 13/16
PA0542*0* DPC25 (25 6/16in) IP12 (11 10/16in) SP31 (30 15/16in) 39 12/16 40 8/16 32 8/16 72 72 33 7/16 32 8/16 N/A 40 2/16 N/A 25 13/16 13 12/16 39 12/16 31 14/16
PA0543*0* DPC25 (25 6/16in) IP12 (11 10/16in) SP33 (32 15/16in) 39 12/16 40 8/16 34 8/16 72 72 35 6/16 34 8/16 N/A 40 2/16 N/A 25 13/16 13 12/16 39 12/16 33 13/16
PA0551*0* DPC25 (25 6/16in) IP14 (13 11/16in) SP29 (28 15/16in) 41 12/16 42 8/16 30 8/16 72 72 31 7/16 30 8/16 N/A 42 2/16 N/A 25 13/16 13 12/16 41 12/16 29 13/16
PA0552*0* DPC25 (25 6/16in) IP14 (13 11/16in) SP31 (30 15/16in) 41 12/16 42 8/16 32 8/16 72 72 33 7/16 32 8/16 N/A 42 2/16 N/A 25 13/16 13 12/16 41 12/16 31 14/16
PA0553*0* DPC25 (25 6/16in) IP14 (13 11/16in) SP33 (32 15/16in) 41 12/16 42 8/16 34 8/16 72 72 35 6/16 34 8/16 N/A 42 2/16 N/A 25 13/16 13 12/16 41 12/16 33 13/16
PA0561*9* DPC25 (25 6/16in) IP29 (28 15/16in) SP29 (28 15/16in) 60x32x2 12/16in 57 57 13/16 32 74 12/16 72 32 31 2/16 59 13/16 58 15/16 N/A 25 13/16 13 12/16 57 3/16 29 13/16
PA0561*0* DPC25 (25 6/16in) IP29 (28 15/16in) SP29 (28 15/16in) 57 57 13/16 30 8/16 72 72 31 7/16 30 8/16 N/A 57 6/16 N/A 25 13/16 13 12/16 57 29 13/16
PA0562*K* DPC25 (25 6/16in) IP29 (28 15/16in) SP31 (30 15/16in) 60x34x2 12/16in 57 57 13/16 34 74 12/16 72 34 33 2/16 59 13/16 58 15/16 N/A 25 13/16 13 12/16 57 3/16 31 14/16
PA0562*0* DPC25 (25 6/16in) IP29 (28 15/16in) SP31 (30 15/16in) 57 57 13/16 32 8/16 72 72 33 7/16 32 8/16 N/A 57 6/16 N/A 25 13/16 13 12/16 57 31 14/16
PA0563*4* DPC25 (25 6/16in) IP29 (28 15/16in) SP33 (32 15/16in) 60x36x2 12/16in 57 57 13/16 36 74 12/16 72 36 35 1/16 59 13/16 58 15/16 N/A 25 13/16 13 12/16 57 3/16 33 13/16
PA0563*0* DPC25 (25 6/16in) IP29 (28 15/16in) SP33 (32 15/16in) 57 57 13/16 34 8/16 72 72 35 6/16 34 8/16 N/A 57 6/16 N/A 25 13/16 13 12/16 57 33 13/16
PA0571*0* DPC25 (25 6/16in) IP31 (30 15/16in) SP29 (28 15/16in) 59 59 13/16 30 8/16 72 72 31 7/16 30 8/16 N/A 59 7/16 N/A 25 13/16 13 12/16 59 29 13/16
PA0572*0* DPC25 (25 6/16in) IP31 (30 15/16in) SP31 (30 15/16in) 59 59 13/16 32 8/16 72 72 33 7/16 32 8/16 N/A 59 7/16 N/A 25 13/16 13 12/16 59 31 14/16
PA0573*0* DPC25 (25 6/16in) IP31 (30 15/16in) SP33 (32 15/16in) 59 59 13/16 34 8/16 72 72 35 6/16 34 8/16 N/A 59 7/16 N/A 25 13/16 13 12/16 59 33 13/16
PA0581*0* DPC25 (25 6/16in) IP33 (32 15/16in) SP29 (28 15/16in) 61 61 12/16 30 8/16 72 72 31 7/16 30 8/16 N/A 61 6/16 N/A 25 13/16 13 12/16 61 29 13/16
PA0582*0* DPC25 (25 6/16in) IP33 (32 15/16in) SP31 (30 15/16in) 61 61 12/16 32 8/16 72 72 33 7/16 32 8/16 N/A 61 6/16 N/A 25 13/16 13 12/16 61 31 14/16
PA0583*0* DPC25 (25 6/16in) IP33 (32 15/16in) SP33 (32 15/16in) 61 61 12/16 34 8/16 72 72 35 6/16 34 8/16 N/A 61 6/16 N/A 25 13/16 13 12/16 61 33 13/16
PA0511*G* DPC25 (25 6/16in) IP6 (5 10/16in) SP29 (28 15/16in) 36x32x2 12/16in 33 11/16 34 8/16 32 74 12/16 72 32 31 2/16 35 13/16 34 15/16 N/A 25 13/16 13 12/16 33 11/16 29 13/16
PA0511*6* DPC25 (25 6/16in) IP6 (5 10/16in) SP29 (28 15/16in) 36x32x2 12/16in 33 11/16 34 8/16 32 74 12/16 72 32 31 2/16 35 13/16 34 15/16 N/A 25 13/16 13 12/16 33 11/16 29 13/16
PA0511*0* DPC25 (25 6/16in) IP6 (5 10/16in) SP29 (28 15/16in) 33 11/16 34 8/16 30 8/16 72 72 31 7/16 30 8/16 N/A 34 1/16 N/A 25 13/16 13 12/16 33 11/16 29 13/16
PA0512*0* DPC25 (25 6/16in) IP6 (5 10/16in) SP31 (30 15/16in) 33 11/16 34 8/16 32 8/16 72 72 33 7/16 32 8/16 N/A 34 1/16 N/A 25 13/16 13 12/16 33 11/16 31 14/16
PA0513*1* DPC25 (25 6/16in) IP6 (5 10/16in) SP33 (32 15/16in) 36x36x2 12/16in 33 11/16 34 8/16 36 74 12/16 72 36 35 1/16 35 13/16 34 15/16 N/A 25 13/16 13 12/16 33 11/16 33 13/16
PA0513*B* DPC25 (25 6/16in) IP6 (5 10/16in) SP33 (32 15/16in) 36x36x2 12/16in 33 11/16 34 8/16 36 74 12/16 72 36 35 1/16 35 13/16 34 15/16 N/A 25 13/16 13 12/16 33 11/16 33 13/16
PA0513*0* DPC25 (25 6/16in) IP6 (5 10/16in) SP33 (32 15/16in) 33 11/16 34 8/16 34 8/16 72 72 35 6/16 34 8/16 N/A 34 1/16 N/A 25 13/16 13 12/16 33 11/16 33 13/16
PA0521*H* DPC25 (25 6/16in) IP8 (7 10/16in) SP29 (28 15/16in) 38x32x2 12/16in 35 11/16 36 8/16 32 74 12/16 72 32 31 2/16 37 13/16 36 15/16 N/A 25 13/16 13 12/16 35 11/16 29 13/16
PA0521*0* DPC25 (25 6/16in) IP8 (7 10/16in) SP29 (28 15/16in) 35 11/16 36 8/16 30 8/16 72 72 31 7/16 30 8/16 N/A 36 2/16 N/A 25 13/16 13 12/16 35 11/16 29 13/16
