OVE PASADENA - Page 33

P. 33
ANNEX IMPERIAL MEASUREMENTS (INCHES)
ANNEXE MESURES IMPÉRIALES (POUCES)
ANEXO MEDIDAS IMPERIALES (PULGADAS)
Note: The * character in the Conguration ID can be replaced by any alphanumerical character. It can be skipped while matching your ID to this table.
Note: Le charactère * dans le Conguration ID peut être remplacé par n’importe quel caractère alphanumérique. Il peut être ignoré en cherchant le ID corresponsant dans la table.
Nota: El carácter * en la Conguration ID se puede reemplazar por cualquier carácter alfanumérico. Puede ignorarse buscando el ID correspondiente en la tabla.
CONFIG
ID
DP IP SP BASE
W
MIN
W
MAX
D H H2 A B C
E
MIN
E
MAX
O P X Y
PA0522*0* DPC25 (25 6/16in) IP8 (7 10/16in) SP31 (30 15/16in) 35 11/16 36 8/16 32 8/16 72 72 33 7/16 32 8/16 N/A 36 2/16 N/A 25 13/16 13 12/16 35 11/16 31 14/16
PA0523*C* DPC25 (25 6/16in) IP8 (7 10/16in) SP33 (32 15/16in) 38x36x2 12/16in 35 11/16 36 8/16 36 74 12/16 72 36 35 1/16 37 13/16 36 15/16 N/A 25 13/16 13 12/16 35 11/16 33 13/16
PA0523*0* DPC25 (25 6/16in) IP8 (7 10/16in) SP33 (32 15/16in) 35 11/16 36 8/16 34 8/16 72 72 35 6/16 34 8/16 N/A 36 2/16 N/A 25 13/16 13 12/16 35 11/16 33 13/16
PA0631*0* DPC29 (29in) IP10 (9 10/16in) SP29 (28 15/16in) 41 5/16 42 2/16 30 8/16 72 72 31 7/16 30 8/16 N/A 41 12/16 N/A 29 7/16 13 12/16 41 5/16 29 13/16
PA0632*0* DPC29 (29in) IP10 (9 10/16in) SP31 (30 15/16in) 41 5/16 42 2/16 32 8/16 72 72 33 7/16 32 8/16 N/A 41 12/16 N/A 29 7/16 13 12/16 41 5/16 31 14/16
PA0633*0* DPC29 (29in) IP10 (9 10/16in) SP33 (32 15/16in) 41 5/16 42 2/16 34 8/16 72 72 35 6/16 34 8/16 N/A 41 12/16 N/A 29 7/16 13 12/16 41 5/16 33 13/16
PA0641*0* DPC29 (29in) IP12 (11 10/16in) SP29 (28 15/16in) 43 6/16 44 2/16 30 8/16 72 72 31 7/16 30 8/16 N/A 43 12/16 N/A 29 7/16 13 12/16 43 6/16 29 13/16
PA0642*0* DPC29 (29in) IP12 (11 10/16in) SP31 (30 15/16in) 43 6/16 44 2/16 32 8/16 72 72 33 7/16 32 8/16 N/A 43 12/16 N/A 29 7/16 13 12/16 43 6/16 31 14/16
PA0643*0* DPC29 (29in) IP12 (11 10/16in) SP33 (32 15/16in) 43 6/16 44 2/16 34 8/16 72 72 35 6/16 34 8/16 N/A 43 12/16 N/A 29 7/16 13 12/16 43 6/16 33 13/16
PA0651*7* DPC29 (29in) IP14 (13 11/16in) SP29 (28 15/16in) 48x32x2 12/16in 45 6/16 46 2/16 32 74 12/16 72 32 31 2/16 47 13/16 46 15/16 N/A 29 7/16 13 12/16 45 6/16 29 13/16
PA0651*0* DPC29 (29in) IP14 (13 11/16in) SP29 (28 15/16in) 45 6/16 46 2/16 30 8/16 72 72 31 7/16 30 8/16 N/A 45 12/16 N/A 29 7/16 13 12/16 45 6/16 29 13/16
PA0652*J* DPC29 (29in) IP14 (13 11/16in) SP31 (30 15/16in) 48x34x2 12/16in 45 6/16 46 2/16 34 74 12/16 72 34 33 2/16 47 13/16 46 15/16 N/A 29 7/16 13 12/16 45 6/16 31 14/16
PA0652*0* DPC29 (29in) IP14 (13 11/16in) SP31 (30 15/16in) 45 6/16 46 2/16 32 8/16 72 72 33 7/16 32 8/16 N/A 45 12/16 N/A 29 7/16 13 12/16 45 6/16 31 14/16
PA0653*2* DPC29 (29in) IP14 (13 11/16in) SP33 (32 15/16in) 48x36x2 12/16in 45 6/16 46 2/16 36 74 12/16 72 36 35 1/16 47 13/16 46 15/16 N/A 29 7/16 13 12/16 45 6/16 33 13/16
PA0653*0* DPC29 (29in) IP14 (13 11/16in) SP33 (32 15/16in) 45 6/16 46 2/16 34 8/16 72 72 35 6/16 34 8/16 N/A 45 12/16 N/A 29 7/16 13 12/16 45 6/16 33 13/16
PA0661*0* DPC29 (29in) IP29 (28 15/16in) SP29 (28 15/16in) 60 10/16 61 7/16 30 8/16 72 72 31 7/16 30 8/16 N/A 61 N/A 29 7/16 13 12/16 60 10/16 29 13/16
PA0662*0* DPC29 (29in) IP29 (28 15/16in) SP31 (30 15/16in) 60 10/16 61 7/16 32 8/16 72 72 33 7/16 32 8/16 N/A 61 N/A 29 7/16 13 12/16 60 10/16 31 14/16
PA0663*0* DPC29 (29in) IP29 (28 15/16in) SP33 (32 15/16in) 60 10/16 61 7/16 34 8/16 72 72 35 6/16 34 8/16 N/A 61 N/A 29 7/16 13 12/16 60 10/16 33 13/16
PA0671*0* DPC29 (29in) IP31 (30 15/16in) SP29 (28 15/16in) 62 10/16 63 7/16 30 8/16 72 72 31 7/16 30 8/16 N/A 63 N/A 29 7/16 13 12/16 62 10/16 29 13/16
PA0672*0* DPC29 (29in) IP31 (30 15/16in) SP31 (30 15/16in) 62 10/16 63 7/16 32 8/16 72 72 33 7/16 32 8/16 N/A 63 N/A 29 7/16 13 12/16 62 10/16 31 14/16
PA0673*0* DPC29 (29in) IP31 (30 15/16in) SP33 (32 15/16in) 62 10/16 63 7/16 34 8/16 72 72 35 6/16 34 8/16 N/A 63 N/A 29 7/16 13 12/16 62 10/16 33 13/16
PA0681*0* DPC29 (29in) IP33 (32 15/16in) SP29 (28 15/16in) 64 10/16 65 6/16 30 8/16 72 72 31 7/16 30 8/16 N/A 65 N/A 29 7/16 13 12/16 64 10/16 29 13/16
PA0682*0* DPC29 (29in) IP33 (32 15/16in) SP31 (30 15/16in) 64 10/16 65 6/16 32 8/16 72 72 33 7/16 32 8/16 N/A 65 N/A 29 7/16 13 12/16 64 10/16 31 14/16
PA0683*0* DPC29 (29in) IP33 (32 15/16in) SP33 (32 15/16in) 64 10/16 65 6/16 34 8/16 72 72 35 6/16 34 8/16 N/A 65 N/A 29 7/16 13 12/16 64 10/16 33 13/16
PA0611*I* DPC29 (29in) IP6 (5 10/16in) SP29 (28 15/16in) 40x32x2 12/16in 37 5/16 38 2/16 32 74 12/16 72 32 31 2/16 39 13/16 38 15/16 N/A 29 7/16 13 12/16 37 6/16 29 13/16
PA0611*0* DPC29 (29in) IP6 (5 10/16in) SP29 (28 15/16in) 37 5/16 38 2/16 30 8/16 72 72 31 7/16 30 8/16 N/A 37 12/16 N/A 29 7/16 13 12/16 37 5/16 29 13/16
PA0612*0* DPC29 (29in) IP6 (5 10/16in) SP31 (30 15/16in) 37 5/16 38 2/16 32 8/16 72 72 33 7/16 32 8/16 N/A 37 12/16 N/A 29 7/16 13 12/16 37 5/16 31 14/16
PA0613*D* DPC29 (29in) IP6 (5 10/16in) SP33 (32 15/16in) 40x36x2 12/16in 37 5/16 38 2/16 36 74 12/16 72 36 35 1/16 39 13/16 38 15/16 N/A 29 7/16 13 12/16 37 6/16 33 13/16
PA0613*0* DPC29 (29in) IP6 (5 10/16in) SP33 (32 15/16in) 37 5/16 38 2/16 34 8/16 72 72 35 6/16 34 8/16 N/A 37 12/16 N/A 29 7/16 13 12/16 37 5/16 33 13/16
PA0621*0* DPC29 (29in) IP8 (7 10/16in) SP29 (28 15/16in) 39 5/16 40 2/16 30 8/16 72 72 31 7/16 30 8/16 N/A 39 12/16 N/A 29 7/16 13 12/16 39 5/16 29 13/16
PA0622*0* DPC29 (29in) IP8 (7 10/16in) SP31 (30 15/16in) 39 5/16 40 2/16 32 8/16 72 72 33 7/16 32 8/16 N/A 39 12/16 N/A 29 7/16 13 12/16 39 5/16 31 14/16
PA0623*0* DPC29 (29in) IP8 (7 10/16in) SP33 (32 15/16in) 39 5/16 40 2/16 34 8/16 72 72 35 6/16 34 8/16 N/A 39 12/16 N/A 29 7/16 13 12/16 39 5/16 33 13/16
