P. 34
ANNEX METRIC MEASUREMENTS (MILLIMETERS)
ANNEXE MESURES MÉTRIQUES (MILLIMÈTRES)
ANEXO MEDIDAS MÉTRICAS (MILÍMETROS)
Note: The * character in the Conguration ID can be replaced by any alphanumerical character. It can be skipped while matching your ID to this table.
Note: Le charactère * dans le Conguration ID peut être remplacé par n’importe quel caractère alphanumérique. Il peut être ignoré en cherchant le ID corresponsant dans la table.
Nota: El carácter * en la Conguration ID se puede reemplazar por cualquier carácter alfanumérico. Puede ignorarse buscando el ID correspondiente en la tabla.
CONFIG
ID
DP IP SP BASE
W
MIN
W
MAX
D H H2 A B C
E
MIN
E
MAX
O P X Y
PA0531*I* DPC25 (645mm) IP10 (245mm) SP29 (735mm) 1016x813x70mm 958 978 813 1899 1829 813 790 1012 989 N/A 656 350 958 758
PA0531*0* DPC25 (645mm) IP10 (245mm) SP29 (735mm) 958 978 775 1829 1829 798 775 N/A 968 N/A 656 350 958 758
PA0532*0* DPC25 (645mm) IP10 (245mm) SP31 (786mm) 958 978 826 1829 1829 849 826 N/A 968 N/A 656 350 958 809
PA0533*D* DPC25 (645mm) IP10 (245mm) SP33 (836mm) 1016x914x70mm 958 978 914 1899 1829 914 891 1012 989 N/A 656 350 958 859
PA0533*0* DPC25 (645mm) IP10 (245mm) SP33 (836mm) 958 978 876 1829 1829 899 876 N/A 968 N/A 656 350 958 859
PA0541*0* DPC25 (645mm) IP12 (296mm) SP29 (735mm) 1009 1029 775 1829 1829 798 775 N/A 1019 N/A 656 350 1009 758
PA0542*0* DPC25 (645mm) IP12 (296mm) SP31 (786mm) 1009 1029 826 1829 1829 849 826 N/A 1019 N/A 656 350 1009 809
PA0543*0* DPC25 (645mm) IP12 (296mm) SP33 (836mm) 1009 1029 876 1829 1829 899 876 N/A 1019 N/A 656 350 1009 859
PA0551*0* DPC25 (645mm) IP14 (347mm) SP29 (735mm) 1060 1080 775 1829 1829 798 775 N/A 1070 N/A 656 350 1060 758
PA0552*0* DPC25 (645mm) IP14 (347mm) SP31 (786mm) 1060 1080 826 1829 1829 849 826 N/A 1070 N/A 656 350 1060 809
PA0553*0* DPC25 (645mm) IP14 (347mm) SP33 (836mm) 1060 1080 876 1829 1829 899 876 N/A 1070 N/A 656 350 1060 859
PA0561*9* DPC25 (645mm) IP29 (735mm) SP29 (735mm) 1524x813x70mm 1448 1468 813 1899 1829 813 790 1520 1497 N/A 656 350 1453 758
PA0561*0* DPC25 (645mm) IP29 (735mm) SP29 (735mm) 1448 1468 775 1829 1829 798 775 N/A 1458 N/A 656 350 1448 758
PA0562*K* DPC25 (645mm) IP29 (735mm) SP31 (786mm) 1524x864x70mm 1448 1468 864 1899 1829 864 841 1520 1497 N/A 656 350 1453 809
PA0562*0* DPC25 (645mm) IP29 (735mm) SP31 (786mm) 1448 1468 826 1829 1829 849 826 N/A 1458 N/A 656 350 1448 809
PA0563*4* DPC25 (645mm) IP29 (735mm) SP33 (836mm) 1524x914x70mm 1448 1468 914 1899 1829 914 891 1520 1497 N/A 656 350 1453 859
PA0563*0* DPC25 (645mm) IP29 (735mm) SP33 (836mm) 1448 1468 876 1829 1829 899 876 N/A 1458 N/A 656 350 1448 859
PA0571*0* DPC25 (645mm) IP31 (786mm) SP29 (735mm) 1499 1519 775 1829 1829 798 775 N/A 1509 N/A 656 350 1499 758
PA0572*0* DPC25 (645mm) IP31 (786mm) SP31 (786mm) 1499 1519 826 1829 1829 849 826 N/A 1509 N/A 656 350 1499 809
PA0573*0* DPC25 (645mm) IP31 (786mm) SP33 (836mm) 1499 1519 876 1829 1829 899 876 N/A 1509 N/A 656 350 1499 859
PA0581*0* DPC25 (645mm) IP33 (836mm) SP29 (735mm) 1549 1569 775 1829 1829 798 775 N/A 1559 N/A 656 350 1549 758
PA0582*0* DPC25 (645mm) IP33 (836mm) SP31 (786mm) 1549 1569 826 1829 1829 849 826 N/A 1559 N/A 656 350 1549 809
PA0583*0* DPC25 (645mm) IP33 (836mm) SP33 (836mm) 1549 1569 876 1829 1829 899 876 N/A 1559 N/A 656 350 1549 859
PA0511*G* DPC25 (645mm) IP6 (143mm) SP29 (735mm) 914x813x70mm 856 876 813 1899 1829 813 790 910 887 N/A 656 350 856 758
PA0511*6* DPC25 (645mm) IP6 (143mm) SP29 (735mm) 914x813x70mm 856 876 813 1899 1829 813 790 910 887 N/A 656 350 856 758
PA0511*0* DPC25 (645mm) IP6 (143mm) SP29 (735mm) 856 876 775 1829 1829 798 775 N/A 866 N/A 656 350 856 758
PA0512*0* DPC25 (645mm) IP6 (143mm) SP31 (786mm) 856 876 826 1829 1829 849 826 N/A 866 N/A 656 350 856 809
PA0513*1* DPC25 (645mm) IP6 (143mm) SP33 (836mm) 914x914x70mm 856 876 914 1899 1829 914 891 910 887 N/A 656 350 856 859
PA0513*B* DPC25 (645mm) IP6 (143mm) SP33 (836mm) 914x914x70mm 856 876 914 1899 1829 914 891 910 887 N/A 656 350 856 859
PA0513*0* DPC25 (645mm) IP6 (143mm) SP33 (836mm) 856 876 876 1829 1829 899 876 N/A 866 N/A 656 350 856 859
PA0521*H* DPC25 (645mm) IP8 (194mm) SP29 (735mm) 965x813x70mm 907 927 813 1899 1829 813 790 961 938 N/A 656 350 907 758
PA0521*0* DPC25 (645mm) IP8 (194mm) SP29 (735mm) 907 927 775 1829 1829 798 775 N/A 917 N/A 656 350 907 758
