OVE PASADENA - Page 35

P. 35
ANNEX METRIC MEASUREMENTS (MILLIMETERS)
ANNEXE MESURES MÉTRIQUES (MILLIMÈTRES)
ANEXO MEDIDAS MÉTRICAS (MILÍMETROS)
Note: The * character in the Conguration ID can be replaced by any alphanumerical character. It can be skipped while matching your ID to this table.
Note: Le charactère * dans le Conguration ID peut être remplacé par n’importe quel caractère alphanumérique. Il peut être ignoré en cherchant le ID corresponsant dans la table.
Nota: El carácter * en la Conguration ID se puede reemplazar por cualquier carácter alfanumérico. Puede ignorarse buscando el ID correspondiente en la tabla.
CONFIG
ID
DP IP SP BASE
W
MIN
W
MAX
D H H2 A B C
E
MIN
E
MAX
O P X Y
PA0522*0* DPC25 (645mm) IP8 (194mm) SP31 (786mm) 907 927 826 1829 1829 849 826 N/A 917 N/A 656 350 907 809
PA0523*C* DPC25 (645mm) IP8 (194mm) SP33 (836mm) 965x914x70mm 907 927 914 1899 1829 914 891 961 938 N/A 656 350 907 859
PA0523*0* DPC25 (645mm) IP8 (194mm) SP33 (836mm) 907 927 876 1829 1829 899 876 N/A 917 N/A 656 350 907 859
PA0631*0* DPC29 (737mm) IP10 (245mm) SP29 (735mm) 1050 1070 775 1829 1829 798 775 N/A 1060 N/A 748 350 1050 758
PA0632*0* DPC29 (737mm) IP10 (245mm) SP31 (786mm) 1050 1070 826 1829 1829 849 826 N/A 1060 N/A 748 350 1050 809
PA0633*0* DPC29 (737mm) IP10 (245mm) SP33 (836mm) 1050 1070 876 1829 1829 899 876 N/A 1060 N/A 748 350 1050 859
PA0641*0* DPC29 (737mm) IP12 (296mm) SP29 (735mm) 1101 1121 775 1829 1829 798 775 N/A 1111 N/A 748 350 1101 758
PA0642*0* DPC29 (737mm) IP12 (296mm) SP31 (786mm) 1101 1121 826 1829 1829 849 826 N/A 1111 N/A 748 350 1101 809
PA0643*0* DPC29 (737mm) IP12 (296mm) SP33 (836mm) 1101 1121 876 1829 1829 899 876 N/A 1111 N/A 748 350 1101 859
PA0651*7* DPC29 (737mm) IP14 (347mm) SP29 (735mm) 1219x813x70mm 1152 1172 813 1899 1829 813 790 1215 1192 N/A 748 350 1153 758
PA0651*0* DPC29 (737mm) IP14 (347mm) SP29 (735mm) 1152 1172 775 1829 1829 798 775 N/A 1162 N/A 748 350 1152 758
PA0652*J* DPC29 (737mm) IP14 (347mm) SP31 (786mm) 1219x864x70mm 1152 1172 864 1899 1829 864 841 1215 1192 N/A 748 350 1153 809
PA0652*0* DPC29 (737mm) IP14 (347mm) SP31 (786mm) 1152 1172 826 1829 1829 849 826 N/A 1162 N/A 748 350 1152 809
PA0653*2* DPC29 (737mm) IP14 (347mm) SP33 (836mm) 1219x914x70mm 1152 1172 914 1899 1829 914 891 1215 1192 N/A 748 350 1153 859
PA0653*0* DPC29 (737mm) IP14 (347mm) SP33 (836mm) 1152 1172 876 1829 1829 899 876 N/A 1162 N/A 748 350 1152 859
PA0661*0* DPC29 (737mm) IP29 (735mm) SP29 (735mm) 1540 1560 775 1829 1829 798 775 N/A 1550 N/A 748 350 1540 758
PA0662*0* DPC29 (737mm) IP29 (735mm) SP31 (786mm) 1540 1560 826 1829 1829 849 826 N/A 1550 N/A 748 350 1540 809
PA0663*0* DPC29 (737mm) IP29 (735mm) SP33 (836mm) 1540 1560 876 1829 1829 899 876 N/A 1550 N/A 748 350 1540 859
PA0671*0* DPC29 (737mm) IP31 (786mm) SP29 (735mm) 1591 1611 775 1829 1829 798 775 N/A 1601 N/A 748 350 1591 758
PA0672*0* DPC29 (737mm) IP31 (786mm) SP31 (786mm) 1591 1611 826 1829 1829 849 826 N/A 1601 N/A 748 350 1591 809
PA0673*0* DPC29 (737mm) IP31 (786mm) SP33 (836mm) 1591 1611 876 1829 1829 899 876 N/A 1601 N/A 748 350 1591 859
PA0681*0* DPC29 (737mm) IP33 (836mm) SP29 (735mm) 1641 1661 775 1829 1829 798 775 N/A 1651 N/A 748 350 1641 758
PA0682*0* DPC29 (737mm) IP33 (836mm) SP31 (786mm) 1641 1661 826 1829 1829 849 826 N/A 1651 N/A 748 350 1641 809
PA0683*0* DPC29 (737mm) IP33 (836mm) SP33 (836mm) 1641 1661 876 1829 1829 899 876 N/A 1651 N/A 748 350 1641 859
PA0611*I* DPC29 (737mm) IP6 (143mm) SP29 (735mm) 1016x813x70mm 948 968 813 1899 1829 813 790 1012 989 N/A 748 350 949 758
PA0611*0* DPC29 (737mm) IP6 (143mm) SP29 (735mm) 948 968 775 1829 1829 798 775 N/A 958 N/A 748 350 948 758
PA0612*0* DPC29 (737mm) IP6 (143mm) SP31 (786mm) 948 968 826 1829 1829 849 826 N/A 958 N/A 748 350 948 809
PA0613*D* DPC29 (737mm) IP6 (143mm) SP33 (836mm) 1016x914x70mm 948 968 914 1899 1829 914 891 1012 989 N/A 748 350 949 859
PA0613*0* DPC29 (737mm) IP6 (143mm) SP33 (836mm) 948 968 876 1829 1829 899 876 N/A 958 N/A 748 350 948 859
PA0621*0* DPC29 (737mm) IP8 (194mm) SP29 (735mm) 999 1019 775 1829 1829 798 775 N/A 1009 N/A 748 350 999 758
PA0622*0* DPC29 (737mm) IP8 (194mm) SP31 (786mm) 999 1019 826 1829 1829 849 826 N/A 1009 N/A 748 350 999 809
PA0623*0* DPC29 (737mm) IP8 (194mm) SP33 (836mm) 999 1019 876 1829 1829 899 876 N/A 1009 N/A 748 350 999 859
