4
825708-0001 Rev- 07/28/2023
©
Copyright 2023 Overhead Door Corporation
CONNECTING RAPID FLEX DOORS
TRANSMITTER
CONNECTIONS:
RECEIVER
CONNECTIONS:
Brown +24V Brown +24V
White Transmitter
White
White Receiver
White
Black N/C
Black Programmable
input
Blue 0V Blue 0V
SECTION 3  CONNECTOR WIRING
