Owasys Owa4X User Manual

%&'"()*+,,-,,.".
14 GND POWER
15 AIN0 Input. Imp:
110K
0 5.12V or
30.72V
0 to 50V
16 DIO-0 Input. Imp:
220K
0-6V 9V -50V 0 to 50V
DIO-0 Open Drain
Output
0,6V@200mA
17 DIO-1 Input. Imp:
180K
0-2V 3.3V -50V 0 to 50V
DIO-1 Open Drain
Output
0,6V@200mA
AIN1 Input. Imp:
68K
0 5.12V or
30.72V
0 to 50V
18 DIO-2 Input. Imp:
180K
0-2V 3.3V -50V 0 to 50V
DIO-2 Open Drain
Output
0,6V@200mA
CAN3L BUS -36V to 36V
19 DIO-3 Input. Imp:
180K
0-2V 3.3V -50V 0 to 50V
DIO-3 Open Drain
Output
0,6V@200mA
CAN3H BUS -36V to 36V
20 DIO-4 Input. Imp:
180K
0-2V 3.3V -50V 0 to 50V
DIO-4 Open Drain
Output
0,6V@200mA
CANL4 BUS -36V to 36V
21 DIO-5 Digital Input 0-2V 3.3V -50V 0 to 50V
DIO-5 Open Drain
Output
0,6V@200mA
CANH4 BUS -36V to 36V
22 DIO-6 Input. Imp: 1K
to +5V
0-1V 1.6V -50V 0 to 50V
DIO-6 Open Drain
Output
0,6V@200mA
iButton BUS 0V to 50V
23 DIO-7 Input. Imp:
180K
0-2V 3.3V -50V 0 to 50V
DIO-7 Open Drain
Output
0,6V@200mA
KLINE 2 BUS -36V to 36V
24 V_IN POWER 9V to 48V /
9V to 36V for
owa4x R4
.1
