Installation

OWC Data Doubler

2.1 Disassembling the Mac mini

Due to the number and variety of screws involved in this process, we commend you use a device to

organize and keep track of the screws, such as an ice cube tray. This will help you to put the screws back in

the correct locations.

INSTALLATION

1. Place the Mac mini upside down, as shown. Use a soft surface such as a towel

or a mouse pad in order to protect the Mac mini from scratches.

2. Rotate the bottom cover counterclockwise to the unlocked position, as shown in the

picture to the left. There is a white dot on the bottom cover. When the bottom cover

is unlocked, this white dot will line up with the corresponding dot on the aluminum

housing. When the bottom cover is unlocked, press on one side of the cover to cause

the opposite side to pop up, then remove it.

3. Remove the two memory modules. The instructions for removing the memory modules

are printed directly to the right of the memory inside the Mac mini, as circled in the

picture to the left.

4. Remove the three Torx T6 screws that secure the fan, as circled in the picture

to the left. The two top screws are shorter; the screw on the lower right is a longer

stando screw.
