MERCURY ELITE PRO DUAL
DEVICE SETUP
4
2.1 QUICK START
If you purchased the OWC Mercury Elite Pro Dual as an empty enclosure, proceed
to Section 2.2, Assembly. If you purchased the Mercury Elite Pro Dual with drives,
the drives ship as a RAID 0 array with the OWC Drive Guide pre-installed to assist
with the formatting process. Follow the steps below to use Drive Guide to format
your drives for Mac (OS X 10.4 and later) or Windows (XP and later). IMPORTANT: if
the RAID mode is changed rst, it will destroy all data on the drives, including Drive
Guide.
1. Plug in the device, then connect it to your computer using the proper cable. If you
prefer to use a dierent formatting utility, do so at this time, skipping the remaining
instructions.
2. Your drive will show up as “OWC SETUP”. Open your drive to view its contents.
3. Double-click the OWC Drive Guide application.
4. Follow the simple on-screen instructions to complete the formatting process.
5. Once the formatting is nished the drive is ready to use.
2.2 ASSEMBLY
NOTE: The following assembly instructions are written for users who purchased the
Mercury Elite Pro Dual as an empty enclosure. The instructions show how to open
the Mercury Elite Pro Dual in order to install drives. If you purchased the Mercury
Elite Pro Dual with drives already installed, opening the Mercury Elite Pro Dual
before the expiration of the original warranty will VOID the warranty. If you wish
to remove or replace the drives after the expiration of the original warranty, you may
do so at that time.
1. Remove the Mercury Elite Pro Dual from its packaging. Set the enclosure on its
side. Use a Phillips screwdriver to remove the two screws highlighted below.
DEVICE SETUP
