Scope of delivery
The RT-XLAN is supplied with all the parts that are needed for use with the RT-Range. Both the base
unit and the client unit come with the same parts. Table 1 and Table 2 list the parts that are delivered
with an RT-XLAN and Figure 1 shows the RT-XLAN and its components.
Table 1. Summary of the RT-XLAN components
RT-XLAN WLAN unit (either base or client, 2.4 GHz or 5 GHz)
2.4 GHz antenna or 5 GHz antenna (depending on configuration required)
Base-to-antenna extension pole
Pump cup suction vehicle mount
110-00274-301 PoE Ethernet to M12 cable
A base unit and a client unit can be identified by a sticker on the side. The IP address is also shown.
Table 2. Additional RT-XLAN Y cable components (where ordered)
14C0147A Y cable for RT-Range or standalone RT
14C0149A cigar plug adapter cable
Figure 1. RT-XLAN components
