Components
The components of the survey trolley are listed in Table 1.
Table 1. RT-Range Survey Trolley components
Item
Qty
Description
1
1
Base plate with wheels attached
2
1
Lower frame assembly with radio antenna plate attached
3
1
Upper frame assembly
4
1
Fixed PC shelf
5
3
Antenna pole sections
6
2
Joint slugs
7
12
M6 × 12 mm hex socket screws
8
12
M6 washers
9
1
UNC bolt
10
2
1" U-Bolt with plate and nuts
11
1
GPS-702-GG antenna
12
4
M4 nuts
13
4
M4 × 40 mm countersunk bolt with locking nuts
14
4
M4 washers
15
2
Bungee straps
16
1
Battery connection cable
(Not shown)
1
Battery charger
(Not shown)
1
Mains cable
(Not shown)
1
Trigger switch
Please note:
Some of these components might already be pre-assembled on delivery. Item numbers refer to the
assembly drawing in Figure 2.
An adapter plate and updated config file is required to support the RT3000 v3, to ensure a secure
mount and accuracy.
The Survey Trolley will require a battery. Please note that this is not supplied by OxTS and must be
purchased by the customer. The ideal battery is a Yuasa NP24-12, a 12 V, 24 Ah lead acid battery
measuring 166 × 175 × 125 mm.
