17
Set the desired direction of rotation by rotating the
ratchet forward/reverse selector (25) (Fig. 11).
Turn on the tool by depressing the variable speed
trigger (5).
Multi Cutter Head
The multi cutter head has been designed for cutting carpets, plastics or cardboard.
Ensure the forward/reverse lever (4) is set to the forward position. Turn on
the tool by depressing the variable speed trigger (5) and wait until the motor
reaches the desired speed.
Move the multi cutter head through the material, running between the blade
guard (29) and the cutter guide (28).
Caution:
Avoid forcing the multi cutter head through the workpiece. Allow the tool
to do the work.
1.
2.
1.
2.
WARNING! Keep hands, hair and loose items of clothing clear of the multi
cutter head. Failure to do so may cause serious personal injury.
Fig. 11
MULTI HEAD TOOL OPERATION
