SUBMERSIBLE
WATER PUMP
350W
INSTRUCTION MANUAL
SPECIFICATIONS
Motor: 350W
Max. Flow Rate: 7,000l/h
Max. Head 5m
Max. Immersion: 5m
Min. Suction Depth 50mm
Max Particle Size: Ø30mm
Water Temp.: 1°C - 35°C
Weight: 4.2kg
PSDW-350
WHAT’S IN THE BOX
Submersible Pump
Universal Adaptor
ozito.com.au
L-Shape Connector

Table of Contents

Questions and Answers

  • B
    Brandi MillerAug 1, 2025
    Why is the flow rate of my Ozito Water Pump reduced?
    • W
      Wendy LopezAug 1, 2025
      If your Ozito Water Pump's flow rate is reduced, start by checking the suction base for partial obstructions and clean it of any foreign matter. Also, inspect the hose/tube for obstructions and remove them. An air leak in the suction line or joints could also be the cause; check these connections and tighten or fix them as needed. Finally, ensure the discharge lines are correctly assembled and of the correct length, adhering to all assembly instructions to prevent air and water leakage.
  • J
    Justin JeffersonAug 6, 2025
    Why does my Ozito PSDW-350 operate intermittently?
    • M
      Megan RuizAug 6, 2025
      If your Ozito Water Pump operates intermittently, the suction base may be blocked and needs cleaning. Ensure the pump is connected to a 230-240V power supply. Also, verify that the fluid being pumped does not contain particles thicker than 30mm. If none of these are the cause, the motor might be faulty, and you should contact Ozito customer service.
  • S
    Shannon WebsterAug 10, 2025
    What to do if my Ozito PSDW-350 Water Pump does not start or pump water?
    • C
      Christina ThompsonAug 11, 2025
      If your Ozito Water Pump isn't starting or pumping water, first ensure it's properly connected to the mains power supply. If connected, check if the float switch is activated; manually raise it if the water level is too low. Also, the impeller might be stuck, so turn off the pump and inspect for any obstructions. In case the thermal overload protection is activated, wait for the motor to cool down, and it should automatically restart. If none of these steps work, the motor may be damaged, and you should contact Ozito customer service.
  • J
    Jared WrightAug 16, 2025
    What to do if Ozito PSDW-350 motor is running but not pumping water?
    • F
      fmitchellAug 16, 2025
      If the Ozito Water Pump is running but not supplying water, the suction base may be obstructed. Clean the suction base to remove any debris. Alternatively, there might be an air lock in the hose/tube or pump. Try several start-ups to remove the air, or lift and tilt the pump slightly while it's running. Also, check if the discharge hose/tube is kinked or damaged; un-kink or replace it if necessary.
  • P
    paulamartinAug 20, 2025
    What to do if my Ozito Water Pump will not turn off?
    • J
      John RomanAug 20, 2025
      If your Ozito Water Pump won't turn off even when the water level is low, it's likely that the float switch is stuck in the 'on' position. Ensure that the float switch is free to operate normally. If the problem persists, contact Ozito customer service.
  • N
    nsmithAug 26, 2025
    How to keep hose/tube on Ozito PSDW-350 universal adaptor?
    • K
      Kristina SantiagoAug 26, 2025
      If the hose/tube doesn't stay on the universal adapter of your Ozito Water Pump while water is flowing, it's possible the hose/tube is slightly wider than the adapter. You can use an adhesive inside the hose/tube, apply Teflon tape around the universal adapter, or use a hose clamp to secure it.

Summary

Setup and Preparation

Universal Adaptor Fitting

Instructions for fitting the universal adaptor to various pipe sizes and fittings.

Operation

L-Shape Connector Installation

Steps to screw the L-shape connector into the pump housing and attach adaptors.

Float Switch Functionality

Explanation of how the float switch controls pump on/off based on water level.

Troubleshooting Guide

Electrical Safety Precautions

General Safety Warnings

Additional Pump Safety Instructions

Spare Parts

Spare Parts List

Detailed list of available spare parts for the submersible water pump.

How to Order Spare Parts

Instructions on ordering spare parts through Bunnings Warehouse or Ozito Customer Service.

Warranty Information

Making a Warranty Claim

Procedure for returning the product for warranty claims, including contact information.

Warranty Terms and Conditions

Details of the 3-year replacement warranty, including exclusions and warnings.

Ozito PSDW-350 Specifications

General IconGeneral
Power350W
Max Head7m
Max. Submersion Depth7m
Particle Size5mm
Voltage230 - 240V
Frequency50Hz
Cable Length10m
Outlet Size25mm
