CHAPTER 12: WIRING DIAGRAMS AND PARTS LIST
PARTS LIST “SE” THREE-PHASE see wiring diagrams n° HC01/3
F2 Battery side output fuse NH00 ........ A-T
TL 3-pole mains contactor + NC / 24VAC
PT Thermal cut-out on transformer
CT Terminal board for voltage change 230/400 V
CM Terminal board for mains regulation
TA Auxiliary transformer 30VA 0-230-400-420-440V / 0-24V
TR Three-phase transformer TA series
RD Diode rectifier bridge PTSxxx/E
SH1 Shunt 100A/100mV or 200A/100mV
P1 ON/OFF green button
PBM753 Electronic control card with microprocessor V1.1
F1 Fuse for card power supply (5x20 glass 500mA quick)
PARTS LIST “SE” SINGLE-PHASE see wiring diagrams n° HD01/2
F2 Battery side output fuse NH00 ........ A-T
TL 4-pole NO mains contactor NO / 24VAC
PT Thermal cut-out on transformer
CM Terminal board for mains regulation
TA Auxiliary transformer 30VA 0-220-230-240-250V / 0-24V
TR Mono phase transformer C2A series
RD Diode rectifier bridge PMSxxx
SH1 Shunt 100A/100mV o 200A/100mV
P1 ON/OFF green button
PBM753 Electronic control card with microprocessor V1.1
F1 Fuse for card power supply (5x20 glass 500mA quick)
