Transmission Gear
Display
Eighth Gear + Manual Mode
The Transmission Gear Display is located
on the digital display and can show the
transmission mode, current gear, and
important transmission conditions:
1 –
18 Forward Gear
R1 – R3 Reverse Gear
R4 – R6
(Pro only)
High-range Reverse
AN Auto Neutral
CA Clutch Abuse
L Low Mode
M Manual Mode
N Neutral
N (green) Neutral Coast
– Shift Position Unknown
! Error State
٭٭
Data Loss
3
Drive, Neutral, and
Reverse Indicator
The Drive, Neutral, and Reverse Indicator
reflects the shifter position for automatic
and automated transmissions. Manual
transmissions and certain automatic
transmissions do not provide feedback to
the display. Instead, the transmission
shifter indicates the gear condition.
Auxiliary Transmission -
Neutral
Iindicates the auxiliary transmission is
engaged and in neutral.
Engine Brake Indicator
This indicator appears when engine
braking (compression brake or exhaust
brake) is enabled. Vehicles capable of
changing the amount of engine braking
show available engine braking levels below
the indicator, with the selected braking
level highlighted. When actively engine
braking, the engine brake indicator turns
2
All popups become suppressible when the parking brake is set.
3
Can show briefly at initial key on.
INDICATIONS - Transmission Gear Display
Y53-1349-1A1 (02/2022) 23
