• Tighten all frame fasteners with a
torque wrench.
NOTE
The torque values and instructions
found in
this section apply ONLY to
Nylon locknuts (right image). They do
NOT apply to the all-metal lock-nut
type (left image).
NOTE
The torque values are applicable to
fasteners on
the FRAME and DO NOT
APPLY to u-bolts for the suspension.
Fasteners with all-metal lock-nuts
Metric Fastener
Size (with all
METAL Lock-
nuts)
T
ightening
Specification lb-ft
(N•m)
M10 29-41 (39.4-55.6)
M12 51-69 (69.1-93.5)
M16 125-165
(169.5-223.7)
M20 230-300
(311.8-406.8)
General considerations when using all-
metal lock-nuts:
• Do not lubricate all-metal lock-nuts.
•
Bolts and washers can be reused,
but nuts can only be reused once.
If reuse history is unknown, install
new nuts.
• If a bolt must be replaced the nut
installed on it must also be
replaced.
• Fasteners must be torqued from
the nut to achieve correct clamp
load.
NOTE
The previous table with torque values
and the
instructions in this section ap-
ply ONLY to all-metal lock nuts (left im-
age) but do NOT apply to Nylon lock-
nuts (right image).
Roadside Assistance
Open 24 hours a day
, 365 days a year
, call
toll-free to talk to someone at the PACCAR
Vehicle Support Center:
• Kenworth customers
SPECIFICATIONS - Roadside Assistance
64 Y53-1349-1A1 (02/2022)
