1. Fill Plug
2. Check Plug
Required tools:
• Small container (to catch fluid)
•
Transmission fluid (See
Transmission Lube Specification on
page 62)
• Standard wrench
• Torque wrench
• 6mm hex bit socket
• 8mm hex bit socket
• Fluid lubricant pump with hose
(optional)
Perform this procedure with the
transmission installed in the vehicle.
CAUTION
DO NOT operate the transmission at
an operating angle greater than 12°
(approximately 21% road grade). The
operating angle
is the transmission
mounting angle plus the road grade
expressed as an angle. Failure to
comply will result in improper transmis-
sion lubrication and may result in
equipment or property damage.
1. Park vehicle on a level surface with
the transmission in neutral, engage
the parking brake, and chock the
tires.
2. T
urn off the engine after it has idled
for two minutes.
12
3. Remove fill plug (1) with wrench.
13
4. Place a suitable container under
the check plug hole.
5. Remove check plug (2) with
wrench.
14
6. Fill transmission at fill hole (1) until
a small amount of fluid runs out of
the check plug hole (2).
15
7. Inspect fill plug and O-ring for
damage. If damaged, replace with
new plug and O-ring.
8.
Insert fill plug with O-ring and
torque plug to 24.5-29.5 N·m
(18-22 lb-ft).
NOTE
Do not over-torque the fill plug or
transmission damage may occur.
9. Inspect check plug and O-ring for
damage. If damaged, replace with
new plug and O-ring.
10. Insert check plug with O-ring and
torque plug to 37-43 N·m
(27.3-31.7 lb-ft).
NOTE
Do not over-torque the check plug or
transmission damage may occur.
12
Idling the engine places oil temperature in the required range for this procedure: 60° F – 120° F (15.5° C – 48.8° C).
13
Fill plug can be accessed beneath the cab, driver side.
14
Check plug can be accessed beneath the cab, driver side.
15
Due to the fill hole location, use of a fluid lubricant pump is advised.
MAINTENANCE - Lubrication
56 Y53-1349-1A1 (02/2022)
