PACIFIC CYCLE KT1165 - Assembly Instructions; Attach the Front Wheel

Assembly
1
2
4
Attach the Front Wheel
1. Place the bushings attached to the front axle into the fork.
2. Push the bushings up into the fork until the locking tabs engage into
the fork holes on both sides of the wheel.
3. Be sure the front wheel is locked into the fork.
4. Push the splash guard tabs into the bushing slots on both sides of
the wheel.
4
front axle
bushing
fork
fork holes
locking tab
bushing slot
splash guard tab
splash guard
front wheel
