Figure 3 – Stand Assembly Connections
** Note: Do not over tighten screws! **
Step 1: Using Table 2 entitled “Detailed List of Stand Parts”, organize
parts A to H into separate areas/piles so you can easily find the part being
called for in steps 2 through 10.
ote: Do not attach the
5 “D” parts until Step 4
Connect and
tighten every joint
with a screwdriver
To Next Page
