Copyright© 2003 Pacific Digital Corporation Page 31
This set of buttons indicates the particular drum pad selected in the
sound-bank/timbre editing menu. After you open a bank name in the
right side menu and select a position, the selected pad number will
blink while selected. Note that Drums 1 & 5 are special drums:
Drum 1 has two timbres (CLOSE and OPEN), while Drum 5 has a
hand-activated pressure switch under the bottom of edge of the drum
pad (this switch is Drum 7 in this menu) with the function of muffled
sound (Tone Mute Choke Control).
B. Save:
Stores (saves) the timbre composition.
C. Add: Adds a new timbre composition.
D. Delete:
Deletes a timbre composition.
E. Name of timbre composition:
Name-input of timbre composition.
F. Apply: Applies the timbre to drum setting.
G. Details of timbre composition: This area gives details of the
timbre composition of all drums.
H. Timbre list: All of the timbres are listed in this area.
I. Exit:
Exits from the Timbre editor and returns to the prior
menu.
7.5.1 Editing Timbres
1. Adding new timbre compositions: To add new
compositions and edit different compositions to your
liking, click “Increase Timbre Composition”
(Figure 18 – Position A).
