SECTION 7 SERVICE
95
7.3 SUB-ASSEMBLY AND CHASSIS COMPONENT PART NUMBERS
The factory part numbers given in the following sections are provided to aid the user in
obtaining spare or repair sub-assemblies and components where the factory has given
permission, in advance, for the user to perform field repairs on the AMX-Series Power Source
.
7.3.1 FACTORY PART NUMBERS, MODEL 105-AMX (PART NUMBER 143141)
SUB-ASSEMBLY FACTORY PART No.
Power Amplifier PCB: 139070
LED Display PCB: 139071
Output Filter PCB: 139073
Low Voltage Power Supply/Fan Speed Cont. PCB: 139074
Control/Logic PCB: 139078
Input Filter PCB: 140079
LVPS Fuse PCB: 140373
CHASSIS COMPONENT FACTORY PART No.
Input Circuit Breaker: 716070 or 716075 for CE
Front Panel Handle: 702112
Output Terminal Block: 705077
Output Terminal Block Cover: 705082
External Sense Terminal Block: 705076
External Sense Terminal Block Cover: 705081
Input Power Cord Strain Relief: 779009
Input Transformer: 531317
Input Power Supply Bridge Rectifier: 743005
Input Power Supply High Voltage DC Capacitor: 720588-41
Output Relay: 717040
Power Amplifier Fan: 703145
7.3.2 FACTORY PART NUMBERS, MODEL 108-AMX (PART NUMBER 143142)
SUB-ASSEMBLY FACTORY PART No.
Power Amplifier PCB: 139070
LED Display PCB: 139071
Output Filter PCB: 139073
Low Voltage Power Supply/Fan Speed Cont. PCB: 139074
Control/Logic PCB: 139078
Input Filter PCB: 140079
LVPS Fuse PCB: 140373
CHASSIS COMPONENT FACTORY PART No.
Input Circuit Breaker: 716070 or 716075 for CE
Front Panel Handle: 702112
Output Terminal Block: 705077
Output Terminal Block Cover: 705082
External Sense Terminal Block: 705076
External Sense Terminal Block Cover: 705081
Input Power Cord Strain Relief: 779009
Input Transformer: 531317
Input Power Supply Bridge Rectifier: 743005
Input Power Supply High Voltage DC Capacitor: 720588-41
Output Relay: 717040
Power Amplifier Fan: 702145
