1

B1d.1

4/06

Supercedes 8/05

PACOPACO

PACOPACO

PACO

PUMPS

INSTALLATION, OPERATION AND

MAINTENANCE INSTRUCTIONS

PACOPACO

PACOPACO

PACO

SPLIT CASE

PUMPS

TYPE KP & TYPE KPV

KP

KPV

Table of Contents

Questions and Answers:

Z
zbaileyAug 12, 2025
Why Paco-Pumps Water Pump does not deliver any liquid at start-up?
- T
  Tammy BurtonAug 12, 2025
  If your Paco-Pumps Water Pump isn't delivering liquid at start-up, it might be due to several reasons: * The pump may not have been properly bled of air; in this case, properly bleed the pump of air. * The pump suction line may not be completely primed; completely prime the pump suction line. * The suction valve might be closed or only partially open; ensure the suction valve is fully open. * The suction strainer could be clogged with dirt or debris; clean or replace the clogged suction strainer.
H
Heather SextonAug 15, 2025
What to do if Paco-Pumps Water Pump runs rough and noisily?
- R
  robin71Aug 15, 2025
  If your Paco-Pumps Water Pump is running rough and noisily, it could be due to: * The impeller may be clogged with debris, so clean the impeller of any debris. * The pump may run rough due to improper balancing of the impeller, so balance the impeller correctly. * The shaft may chatter because it is bent, so replace the bent shaft.
B
Brittany JacksonAug 19, 2025
Why is my Paco-Pumps Water Pump using too much power?
- B
  Bethany BeanAug 19, 2025
  If your Paco-Pumps Water Pump is using too much power, it could be that the total head of installation (back pressure) is higher than the rated total head of the pump. To resolve this, check and adjust the installation head pressure.

Paco-Pumps KP Specifications

General

Type	Centrifugal Pump
Application	Water Supply
Impeller Type	Open
Casing Material	Cast Iron, 316 Stainless Steel
Inlet Diameter	25-200 mm
Outlet Diameter	25-200 mm
Material	Cast Iron, 316 Stainless Steel

Summary

Installation - Mechanical

Location

Pump Foundation

Install pump on a firm, concrete foundation pad to dampen vibration and prevent misalignment.

Suction (Inlet) Piping

Size and install suction piping to minimize loss and ensure flow; avoid high points.

Mechanical Seals

Coupling Alignment

Align pump and motor coupling hubs accurately to within .005" runout.

Operation

Priming

Pump is not self-priming; must be completely filled with liquid before starting.

Pre-Start Checklist

Inspect piping cleanliness, wiring, voltage, rotation, and secure fittings before starting.

Motor Rotation

Starting the Pump

Ensure coupling guard is in place; open suction valve, crack discharge valve, start motor.

Pump Shutdown

Maintenance

Pump Bearing Lubrication - General Comments

Stuffing Box Packing Shaft Seal - Water Lubrication

Bearing, Seal, & Packing Replacement

Covers procedures for replacing bearings, mechanical seals, and packing.

Disassembly of Horizontal Pumps

Disassembly of Vertical Pumps

Component Inspection

Reassembly of Pumps

Trouble Shooting

Symptoms

Lists common pump symptoms and their corresponding cause codes for diagnosis.

Possible Causes

Provides a list of potential causes for pump operational issues, referenced by cause codes.
