Megabit Modem CRA-C User Manual 17
CONFIGURE AND VIEW STATUS
In this chapter, you configure the Megabit Modem CRA-C or view system
status using an ASCII terminal connected to the console port. Go to
the following sections:
To complete this task
Go to page
Connect to an ASCII terminal 17
How to log on and navigate the menus 19
How to configure a remote unit 23
Configure the system settings 24
Configure the ADSL transceiver 26
Configure the Bridge/Router 30
View status 41
Log out 49
Connect to an ASCII Terminal
Connect the Megabit Modem CRA-C to an ASCII terminal:
1 Plug the console adapter into the standard 9-pin COM port on
the ASCII terminal and tighten the captive screws until they are
snug (Figure 7). (Skip this step if the ASCII terminal has an
RJ-48 jack.)
2 Connect one end of the silver console cable to the
console adapter.
3 Connect the other end of the silver console cable to the console
port on the Megabit Modem CRA-C rear panel.
