Configure and View Status
Megabit Modem CRA-C User Manual 43
ADSL Performance Status. The ADSL Performance Status screen is
updated every second and provides a summary of the ADSL parameters and
outstanding ADSL-related alarms. This screen displays the upstream and
downstream ADSL links. The SNR (signal-to-noise ratio) margin column
displays both the current SNR margins as well as the minimum SNR margins
for the current 24-hour period.
Press
1
1
on the ADSL Menu to display the ADSL Performance Status screen.
07/02/97 PAIRGAIN TECHNOLOGIES 08:45:10
ATU-C ADSL MEGABIT MODEM TERMINAL 01.01
ADSL PERFORMANCE STATUS
DOWN ALARMS: NONE
UP ALARMS: NONE
SYSTEM STATE: DATA
DOWNSTREAM UPSTREAM
---------- --------
cur/min cur/min
SNR MARGIN (dB): 13.1/13.1 7.6/7.6
LINE ATTN -0.1 -0.7
24 HOUR ES: 3 3
24 HOUR UAS: 38 38
DATA RATE (kbps): 3168 1080
(C)lear (R)eturn (M)ain
ENTER CHOICE-->
Do not type
C
C
unless you want to clear the ADSL
performance and alarm counters in both the local and
remote units.
Type
C
C
to clear the ADSL performance and alarm counters. This also clears
the counts in the remote Megabit Modem CRA.
Table 13 describes the ADSL Performance Status screen fields.
