Unpacking Information
Thank you for purchasing the Pakedge Device & Software SE-8P4 gigabit switch.
Before installation, please verify that your package contains the following items.
1. One 8-Port Gigabit Ethernet with 2-Port PoE+/4-Port PoE Switch
2. One AC power cord
3. Rubber feet and screws
4. Rack-mount brackets and screws (included, optional use)
5. User Manual
Introduction
General Description
The SE-8P4 provides 8*10/100/1000Mbps Gigabit ports with 4-port PoE+/PoE,
making it an excellent choice for a fast, cost effective and reliable networking
infrastructure. The store-and-forward architecture filters errors and forwards packets
in a non-blocking environment. Flow control ensures the accuracy of the data
transmitted. The PoE+ on the SE-8P4 supplies power for connected devices that
need it. Over current protection and circuit shorting protection are also supported.
The switch was designed for easy installation and maintenance. It supports the
Nway auto-negotiation protocol that detects networking speed (10/100/1000 Mbps)
and duplex modes (Full/Half) automatically. Auto-MDI/MDI-X function alleviates the
need for crossover cables. Also, rich diagnostic LEDs are provided for real-time
connection status information.
Key Features
Complies with 10BASE-T specifications of the IEEE802.3 standard
Complies with 100BASE-TX specifications of the IEEE802.3u standard
Complies with 1000BASE-T specifications of the IEEE802.3ab standard
Compliant with IEEE 802.3af/at PoE standard (DTE power via MDI)
Provides 4 PoE ports with classification identify
Supports 15.4W maximum per PoE port
Supports 31.5W maximum per PoE+ port
Supports over current protection and circuit shorting protection
8 * RJ-45 ports for 100BASE-TX and 1000 BASE-T and 10BASE-T connectivity
Provides 8* 10/100Mbps auto-detect（half/full） and 1000Mbs full duplex switch
