Handling and Operation
6
Subject to change without notice
23
Group 4 description
(1) Scroll A flashing "scroll” key signals that further menu items are
available. These can be accessed by pressing the key.
(2) Minus Enters minus values
(3) Calculator
(4) Elevation table down Only works when the machine has stopped
(5) Manual welding Only works when the machine has stopped
(6) Enter Saves newly entered values
(7) Delete Deletes values called up
Group 3 description
Information which is normally standard and cannot be altered, appears on the display.
Abb.1937-03
(1) Homepage Back to the homepage
(2) Status line
(3) Menu items Selection and display of menu items
(4) Standard info
Standard information:
Batch counter 0
Batch selected 50
Total counter 0
Examples / h 0
Speed (m/min) 0
!
CAUTION
Machine damage by pulling the power supply plug.
Electronic components can be damaged.
Only pull the power plug when the main switch is switched off..
