121
Lifting the Platform
Press the pushbuttons (27) and optionally (29) simultane-
ously and hold them in this position until the platform has
reached the vehicle loading floor height.
The platform tilts to the horizontal or preset position before
it is lifted.
Setting the Platform to its Horizontal Position
To adjust a steeper tilt of the platform, press both
pushbuttons (27), (32) and optionally (29) simultaneously
and hold them in this position until the platform has reached
the required tilt angle.
To adjust a flatter tilt of the platform, press both
pushbuttons (28), (32) and optionally (29) simultaneously
and hold them in this position until the platform has reached
the required tilt angle.
Extending and Folding Out the Platform
Loosen the platform interlock (if present).
Press the pushbuttons (28) and optionally (29) simultane-
ously and hold them in this position until the platform has
completely lowered.
The platform is lowered so that it can be extended without
obstruction.
Press the pushbutton (30) and hold it in this position until
the platform is completely extended.
Press the pushbuttons (28) and optionally (29) simultane-
ously and hold them in this position until the folded platform
has made contact with the ground.
Protect your hands with gloves.
Pull the handle with both hands to unfold the folding part of
the platform.
Folding In and Retracting the Platform
Protect your hands with gloves.
Pull the handle with both hands to fold back the folding part
of the platform.
Close the platform interlock (if present).
Press the pushbuttons (27) and optionally (29) simultane-
ously and hold them in this position until the platform has
reached the retraction height.
