Palfinger MBB C 750 S - Retractable Tail Lifts

20
Retractable Tail Lifts
F G
1 Guide rails
2 Supporting strap on body
(not in scope of delivery)
3 Lateral operating panel
4 Hydraulic unit
6 Lift arms switch b13,
tilt sensor b15
7 Lift arms switch b16,
tilt sensor b15
8 Guide pulley
10 Foot control (optional)
11 Roll stop (roll-off
protection, optional)
12 Payload center of gravity
13 Warning lights (optional)
15 Folding part of platform
16 Stationary part of platform
17 Torsion frame
18 Lift cylinder
19 Tilt cylinder
21 Support tube
22 Hand cable control
24 Guide cylinder
3
24
12
13
11
15
10
4
2
1
3
16
21
19
18
17
6
8
7
22
