Palfinger MiniFix User Manual (English)

Questions and Answers:

C
Christina RyanAug 3, 2025
What to do if my Palfinger Lifting Systems liftgate is completely dead?
- R
  Ronald TuckerAug 3, 2025
  If your Palfinger Lifting System liftgate is completely dead, with no clicking or movement, there are several things you can check: * First, check the cab shut-off switch. * Next, inspect the circuit breaker at the main batteries. * Ensure the vehicle batteries are charged. * Examine the fuse in the power pack. * Verify the ground connection to the power pack is secure. * Check the oil level in the power pack reservoir. * Finally, look for any mechanical or electrical damage, such as damaged cables.
F
floreswilliamAug 9, 2025
What to do if On-Off L.E.D.s are on but all functions are dead on Palfinger Lifting Systems?
- F
  feliciarodriguezAug 9, 2025
  If the L.E.D.s on your Palfinger Lifting Systems are on but all functions are dead, try disconnecting the plugs and reboot the board by unplugging J-1 for 5 seconds, then plug it back in.
R
rebecca43Aug 15, 2025
Why does the platform tilt down before it reaches the ground on my Palfinger Lifting Systems?
- V
  Vicki FosterAug 15, 2025
  If the platform of your Palfinger Lifting Systems tilts down before it reaches the ground, it could be due to the tilt angle of the B-13 sensor being incorrectly adjusted. Try adjusting the B-13 lift arm switch.
W
William YoungAug 22, 2025
How to fix L.E.D.s that continue to stay on after switch is turned off in Palfinger Lifting Systems?
- A
  Andrew MarshAug 22, 2025
  If the L.E.D.s continue to stay on after the switch is turned off on your Palfinger Lifting Systems, ensure the platform is closed and stored vertically. Also, adjust the B-16 switch. If the issue persists, unplug J-3(w/l and f/c), J-41(B-13, B16) and J-31(Hand control), jump J-11 #4 to J-41 #GN. If the issue still persists, unplug J-1 (Main power), wait 10 seconds and plug J-1 back to the board. If the issue still persists, plug each connector back, one at a time, and check the functions of the gate after plugging in each.
M
mperezAug 27, 2025
What to do if the platform does not tilt properly after reaching the ground on Palfinger MiniFix?
- C
  Christine SalazarAug 27, 2025
  If the platform on your Palfinger Lifting Systems does not tilt or tilts unsteadily after reaching the ground, it could be due to several reasons: 1. The flow valve R5 or shuttle valve may be jammed or defective; in this case, adjust or replace them. 2. The tilt angle switch B13 may be adjusted incorrectly or defective; in this case, check the sensor and its tilt angle. 3. The PC-Board may be defective; in this case, replace it. 4. The solenoid valve S3 on the tilting cylinder may be soiled or defective; in this case, clean or replace it.

Palfinger MiniFix Specifications

General

Brand	Palfinger
Model	MiniFix
Category	Lifting Systems
Language	English

Summary

Important Notes

Attention

Safety alert symbol and its meaning for potential personal injury hazards.

General Operational Notes

Overview of the liftgate's design, hydraulic system, and electrical supply.

General Information

Fleet manager responsibility for operator education, safety, and load limits.

Safety Information

Hazard Alert Definitions

Defines DANGER, WARNING, CAUTION, and NOTICE symbols for safety communication.

Basic Parts in Detail

General View of Liftgate

Identifies key components like platform, side control, power pack, and cylinders.

MiniFix Control System

Details the components and wiring for the control systems.

Maximum Load and Placing of Load on Platform

Maximum Load Rating

Explains how load capacity decreases with distance from the truck body.

Load Diagram Explanation

Illustrates the relationship between distance and liftgate capacity.

Operation of Liftgate

3 Button Side Control Operation

Instructions for operating the liftgate using the external 3-button control.

Hand Held Remote Control Operation

How to use the wired hand-held remote control for lifting and lowering.

Foot Control Operation

Instructions for operating the liftgate using the optional foot control switches.

Wireless Hand Held Remote Operation

Guide to operating the liftgate with a wireless remote control.

Cart Stops Usage

How to use the platform's cart stops for securing rolling containers.

Preventive Maintenance and Quick Check

Maintenance and Care Schedule

Recommended intervals for cleaning, lubrication, and general inspections.

Lubrication Procedures

Details on greasing bearing points and checking oil levels in the power pack.

Recommended Hydraulic Fluids

Lists suitable hydraulic fluid brands and types for various temperature ranges.

Quick Check List

Daily, weekly, or monthly checks to ensure safe and proper liftgate function.

Troubleshooting

Basic Function Checks

Steps to diagnose common issues like a dead liftgate or unresponsive functions.

On-Off L.E.D.s and Stuck L.E.D.s

Troubleshooting for liftgate LEDs being on or stuck on after power off.

Platform Tilting Issues

Diagnosing and fixing platform tilting down before reaching the ground.

Lift Gate Malfunction Causes and Remedies

Electrical and Hydraulic Schematics

Wiring Diagram

Schematic illustrating the electrical connections of the liftgate system.

Electrical Schematic

Detailed diagram of the liftgate's electrical components and circuits.

Connector Overview

Visual guide to the connectors on the control panel, power pack, and circuit board.

Hydraulic Schematic

Diagram showing the hydraulic system, valves, and flow paths.

Needed Information for Ordering Spare Parts and Repairs

Ordering Spare Parts Information

Required details for ordering correct spare parts, including model and serial number.

Repair Procedures

Guidelines for sending parts for repair and required documentation.

Warranty Information

Warranty Coverage Schedule

Details the warranty duration for different liftgate components.

Contact Information

PALFINGER Liftgates Contact Details

Phone numbers, fax, and email addresses for customer service and technical support.
