Revision 1.1 7
3.2 MiniFix Control System
3.2.1 Control System until June 2008
No. Description Part no.
3 Cable for push button P-2005 043
4 Cab on-off switch P-1332 494
5 Sensor B13 for lift arm - 2 wire P-1404 177
6 Sensor B16 for platform - 3 wire P-1404 176
7 2 foot control button with harness P-1404 178
8 Cable for solenoid valve P-67254198
9 PC board - earlier style P-1407 378
10 Foot control button P-1405 256
11 Contact block for tilt function P-67487729
12 Button with cap P-67476085
13 Plate, operation P-2005 348
14 Contact block for lift function P-67487710
