Explanation of Terms
Actions for the platform:
•Open
The platform opens and moves from the vertical transport po-
sition to the desired operating position. This position is stored
and reverted to when lifting the platform after the ground ad-
justment.
•Close
The platform closes and moves from the horizontal operating
position to the vertical transport position.
• Extend
The platform extends from under the vehicle.
• Retract
The platform retract under the vehicle.
• Fold out
The platform folds out from the transport position to the oper-
ating position.
• Fold in
The platform folds in from the operating position to the trans-
port position.
•Lower
The platform moves in horizontal position downwards.
•Lift
The platform moves in horizontal position upwards.
