Operation with Two-hand Control easy move
26 Optional: key control, rotary switch,
emergency-off pushbutton, E30 key
27 Rotary switch: lift/lower
28 Rotary switch: open/close
29 Rotary switch: additional pushbutton
30 Rotary switch: Retract and extend
32 Locking lug
39 Operating panel
Note: These instructions describe the standard range of prod-
ucts. Special product lines may differ from the descriptions
in here or may have enhanced functions. For a detailed de-
scription of your product type, please contact our customer
service.
29
26 (optional):
32
28
30
27
39
easy move
DANGER!
Risk of accidents and injury!
If the instructions in chapter "General Information" are not ob-
served during operation of the tail lift, personal injuries and
material damage can occur.
Before operating the tail lift, read chapter “General Opera-
tion” from p. 26.
