Pall LevMixer DB-300 User Manual

Document #: 020-17475-00 Revision: E Page #: 5 of 63
C. SPECIFICATIONS
Table1. Specifications sheet
Footprint (in. & mm) WxLxH:
16” x 44” x 36” (compact configuration)
16” x 51.6” x 36” (expanded)
Control box, cart, & mixer
enclosure material:
304L Stainless Steel
Control box, cart, & mixer
enclosure surface finish
At least 35 µin. Ra / 0.89 µm Ra
Control box ingress rating:
IP 65
Enclosure ingress rating:
IP 23
Voltage:
100-230VAC,50/60Hz
Input Wattage:
Less than 350W
Amperage:
100V 2.8A; 110V 2.5A ; 230V 1.5A
Voltage fluctuation:
+/- 10%
Altitude rating:
1000m
Max humidity:
85%, avoid condensation
Ambient temperature:
4-40°C
Motor horsepower:
1/8hp
Power cord length:
20 ft (600 cm)
Power cord plug options:
US, Continental Europe, Swiss, Australia, Japan, UK
E-stop (present, yes/no,
location):
Yes, face of control box
Min and Max speed:
20 to 210 RPM
Connections for remote
output/control:
TURCK RSFPV61, RSFPV579
Functions available from
remote control panel:
Motor - start, stop. Speed – adjustment, indication. Alarm –
indication. Mode of control (remote/local) – indication
Signal type(s) for remote
output/control:
Impeller speed out 4-20mA, motor control
in 0-10 VDC, discrete I/O signals relay contact type
Alarms generated:
Motor failure, impeller coupling failure, speed off-range failure,
cryocooler failure, E-stop activation
Mixer charge time:
35 minutes
Operator interface type:
Touchscreen PLC
Method for RPM
measurement:
Direct measurement of impeller speed via non-contact
magnetic sensor
Noise level at operator
position:
67dB
Casters:
2X swivel (front), 2X stationary (rear)
Wheel material:
Polyurethane
Recipe storage:
Yes. Up to 10 can be stored. Up to ten instructions in each
recipe are executed sequentially. Each instruction contains
individual programmable parameters: mixing time, pause
time, and speed.
Password protection:
Operator level: access to protected function - start recipe run.
Supervisor level: access to protected functions - Recipe Editor,
Pause or Abort Recipe run, Switch of Control between Local
to Remote, adjustment of set up for reduced set of
parameters. Maintenance level: access to protected
functions – Program Setup parameters, System parameters
and includes Supervisor level of access.

Pall LevMixer DB-300 Specifications

General

Brand	Pall
Model	LevMixer DB-300
Category	Mixer
Language	English
