Pall LevMixer DB-300 User Manual

Document #: 020-17475-00 Revision: E Page #: 56 of 63
Table8. Remote Control I/O Chart
(See schematic in Figures 63 and 64)
ANALOG I/O CONNECTOR CIRCUITS
PIN#
CIRCUIT DESCRIPTION
RANGE
CALIBRATION
2, 3
Speed output 4-20mA
0-210 RPM
4mA=0% of range
20mA=100% of range
4, 5
Speed set point input 0-10VDC
0-210 RPM
0V=0% of range
10V= 100% of range
DISCRETE I/O CONNECTOR CIRCUITS
PIN#
CIRCUIT DESCRIPTION
SIGNAL TYPE
LOGIC
1, 2
Motor Start/Stop input
Relay contact
Open=Stop
Closed=Run
3, 4
Remote status output
Relay contact
Open=Local Control
Closed=Remote Control
5, 6
Alarm output
Relay contact
Open=No Alarm
Closed=Alarm
The analog speed control input 0-10 V (pins 4 and 5 of analog input connector) has an
impedance of 500 kOhm. The safe input voltage range is -0.5V to +15V
For the analog output 4-20 mA (pins 2 and 3 of analog I/O connector) the MAX load
resistance should not exceed 500 Ohm.
For equipment safety and to avoid possible excess noise on the speed control input
signal (pins 4, 5 of Analog I/O connector) it is recommended to include an Isolation
Amplifier in the design of the 0-10 VDC remote control external circuitry.
Table9. List of Electrical Components
(See schematic on Figures 63 and 64)
Item
Description
1
Power cord assembly
2
5A fuse
3
Power button
4
LED light bulb
5
RFI filter
6
24 VDC 60W power supply
7
Touch screen PLC
8
RJ45 Socket
9
5-pin receptacle TURCK # RSFPV 579
10
6-pin receptacle TURCK # RSFPV 61
11
E-Stop button
12
12-pin cordset
13
Sensor ring assembly
14
7-pin cordset
15
Cryomodule assembly
16
Cryomodule Ground wire
17
Motor, motor controller & cables
18
24 VDC power supply
19
24V power supply input harness
20
Wired fan
