Palstar HF-AUTO - Setup Mode

ON INITIAL POWER-UP
Display will indicate rev level of software and Palstar
copyright information.
SCREEN DISPLAY ON POWER-UP
Page 3
PRESS
TO SELECT
C AND L
TO SELECT
SETUP ITEM
ANT #1
ANT #2
ANT #3
AUTO
MANUAL
BYPASS
SETUP
MODE
TUNE KNOB
PRESS
PRESS
ANTENNA
PALSTAR
SETUP MODE
RANGE (WATTS):
TUNE LEVEL:
BACKLIGHT:
POWER UP MODE:
STEP SPEED:
AUTO ANT SW:
RETUNE DELAY:
POWER UP ANT:
AUTO STORE:
DELAY TUNE SWR:
LAST SWR DISP:
LAST POWER DISP:
100 | 250 | 1000 | 2500
1 – DIM | 2 - BRIGHT
AUTO | MANUAL | BYPASS
HIGH | MED | LOW
ON | OFF
ADJ 1-3 SECS
ANT 1 | 2 | 3
ON | OFF
ON | OFF
ON | OFF
ON | OFF
1.50
FOR LICENSED USERS ONLY
MARS MIN-MAX
MARS FREQ ADJ
to SELECT MENU
PRESS
TUNE KNOB
PRESS
& ADJUST
with TUNE KNOB
to ADJUST VALUES
PRESS
RED BUTTONS
*Recommended settings in bold.
