Servo reference
As the servo reference signal, this unit automatically selects the input video signal selected
by the VIDEO INPUT switch, the reference video signal which is supplied from the REF
VIDEO input connector or the internal sync signal.
When the signal is selected, the unit’s mode and servo reference stand in the relationship
shown in the flowchart presented below.
EXT
1
2
What is the SERVO REF on the setup
menu No. 304 setting?
Is the unit in the recording or editing
mode?
3
Is the REF VIDEO signal supplied?
YES
YES
AUTO
YES
NO
NO
NO
Is the input video signal
available?
The REF VIDEO input
signal serves as the
reference signal.
The internal sync signal
serves as the reference
signal.
The input video signal
serves as the reference
signal.
