Connector signals
VIDEO IN
SERIAL IN (DIGITAL) BNC × 2 Active through (Option)
Y, PB, PR (ANALOG) BNC × 3
VIDEO IN BNC × 2
Loop-through, 75Ω termination
switch provided
REF VIDEO IN BNC × 2
Loop-through, 75Ω termination
switch provided
S1-VIDEO IN 4-pin × 1
VIDEO OUT
SERIAL OUT(DIGITAL) BNC × 3 (Option)
Y, PB, PR (ANALOG) BNC × 3
VIDEO OUT BNC × 3
S1-VIDEO OUT 4-pin × 1
AUDIO IN
SERIAL IN (DIGITAL) BNC × 2 Active through (Option)
AUDIO IN (DIGITAL) BNC × 1 CH1/CH2 AES/EBU format
AUDIO IN (ANALOG) XLR × 2 CH1, CH2
TIME CODE IN BNC × 1
AUDIO OUT
SERIAL OUT (DIGITAL) BNC × 3 (Option)
AUDIO OUT (DIGITAL) BNC × 1 CH1/CH2 AES/EBU format
AUDIO OUT (ANALOG) XLR × 2 CH1, CH2
TIME CODE OUT BNC × 1
MONITOR OUT PHONO × 1
HEADPHONES (front) 1/4" phone × 1
IEEE1394
IN/OUT 6-pin × 1 (Option)
RS-422A REMOTE (9P)
REMOTE
Pin No.
Signal
Pin No.
Signal
Pin No.
Signal
1 FRAME GROUND 4
RECEIVE COMMON
7 TRANSMIT B
2 TRANSMIT A 5 ————— 8 RECEIVE A
3 RECEIVE B 6
TRANSMIT COMMON
9 FRAME GROUND
Pin No. Signal
1
2
3
GND
HOT
COLD
