49
RS-232C REMOTE (25-pin D-SUB straight cable supported)
Pin No. Abbreviation Circuit Description
1 FRAME GROUND Protective ground Frame ground
2 TxD Transmitted data Receives data from the PC.
3 RxD Received data Sends data to the PC.
4 RTS Request to send Shorted with pin 5.
5 CTS Clear to send Shorted with pin 4.
6 DSR Data set ready
Positive power output after communication
enable status
7 SG Signal ground Signal ground
20 DTR Data terminal ready No processing
ENCODER REMOTE (15P)
Pin No.
Signal
Pin No.
Signal
Pin No.
Signal
1 ————— 6 SYSTEM H 11 RET GND
2 SET UP 7
SYS.SC COARSE (2)
12 —————
3 C LEVEL 8 –9V 13 —————
4 GND 9 HUE 14 SYS.SC FINE
5 +9V 10 VIDEO LEVEL 15
SYS.SC COARSE (1)
