F1 board
AUDIO
SW100 Audio Input
Impedance SW
SW101
HIGH
This sets the CH1 audio input
impedance.
HIGH/600Ω
HIGH
Abbr.
name
Full name Function
Factory
setting
Audio Input
Impedance SW
This sets the CH2 audio input
impedance.
HIGH/600Ω
