Appendix
Specifi cations
This page provides the specifi cations for the basic model.
The model number is different according to the unit confi guration.
To check the model number:
Check the bottom of the computer or the box the computer came in at the time of purchase.
To check CPU speed, memory size and the hard disk drive (HDD) size:
Run the Setup Utility (
Reference Manual “Setup Utility”) and select [Information] menu.
[Processor Speed]: CPU speed, [Memory Size]: Memory size, [Hard Disk]: Hard disk drive size
Main Specifi cations
Model No. CF-C2ACAZZBM CF-C2ACAZZCM CF-C2ACAZZDM
CPU
Intel
®
Core™ i5-3427U Processor (3
MB
*1
cache, up to 2.8
GHz
) with Intel
®
Turbo Boost Tech-
nology
Chipset Mobile Intel
®
QM77 Express Chip set
Video controller Built-in Chip Set
Memory
*1*2
4
GB
(8
GB
Max.)
Video Memory
*1*3
UMA 1664
MB
Max. (When
memory is either 4
GB
or
8
GB
)
UMA <32-bit> 1416
MB
Max. <64-bit> 1696
MB
Max. (When
memory is either 4
GB
or 8
GB
)
Hard Disk Drive
*4
500
GB
Approx. 10
GB
is used as a
partition with HDD recovery
tools. (Users cannot use this
partition.)
Approx. 1
GB
is used as a
partition with system tools.
(Users cannot use this parti-
tion.)
Approx. 20
GB
is used as a
partition with HDD recovery
tools. (Users cannot use this
partition.)
Approx. 300
MB
is used as
a partition with system tools.
(Users cannot use this parti-
tion.)
Approx. 15
GB
is used as a
partition with HDD recovery
tools. (Users cannot use this
partition.)
Approx. 300
MB
is used as
a partition with system tools.
(Users cannot use this parti-
tion.)
Display Method 12.5 HD type (IPS)
Internal LCD
*5
65,536/16,777,216 colors (1366 × 768 dots)
External Display (HDMI)
*6
65,536/16,777,216 colors (1920 x 1200 dots Max.)
Wireless LAN
*7
Intel
®
Centrino
®
Advanced-N 6235 (
page 40)
Bluetooth
*8
page 40
Wireless WAN
*9
Sierra™ Wireless High-speed module
LAN IEEE 802.3 10Base-T/IEEE 802.3u 100Base-TX/IEEE 802.3ab 1000Base-T
Modem
*10
Data: 56
kbps
(V.92) FAX: 14.4
kbps
Sound WAVE and MIDI playback, Intel
®
High Defi nition Audio subsystem support, Monaural speaker
Security Chip TPM (TCG V1.2 compliant)
*11
Camera Front 1280 × 720 dots, 30 fps (Video), Monaural Microphone
Rear
*12
1280 × 720 dots, 30 fps (Video) / 2048 x 1536 dots (Still)
Sensor Ambient light
sensor
Equipped
Magnetic sen-
sor
Gyro sensor
Acceleration
sensor
Card Slot ExpressCard
*13
ExpressCard/34
Smart Card
*14
x 1, Half Size Smart Card slot x 1
*15
SD Memory
Card
*16
x 1
RAM Module Slot
DDR3L SDRAM, 204-pin, 1.35
V
, SO-DIMM PC3L-10600 Compliant
*3
Interface USB port 2.0 x 1, 3.0 x 2
*17
, Serial Port (Dsub 9-pin male)
*18
, Modem port (RJ-11)
*10
, LAN port
(RJ-45), VGA port (Mini Dsub 15-pin female)
*19
, HDMI Port (Type A)
*20
, NFC (Near Field Com-
munication) Sensor
*21
, Expansion Bus Connector (Dedicated 100-pin female), Microphone
Jack (Miniature jack, 3.5 DIA, Stereo), Headphone Jack (Miniature jack, 3.5 DIA, Impedance
32
, Output Power 4
mW
x 2)
