Handling and MaintenanceHandling and Maintenance
■ Remove the built-in battery
1. Turn off the computer, and disconnect the AC adaptor.
Do not remove the built-in battery when the computer is in the sleep/hibernation mode.
2. While pressing the HOLD button, slide and hold the power switch for 5 seconds or longer.
This operation will stop the output from the built-in battery.
3. Flip the computer over, remove the main battery pack.
While sliding the right and left latches to the direction to unlock them, lift up the battery pack slightly,
and remove it. (è page 7)
4. Remove the screws, and then remove the cover.
Remove all the screws on the bottom.
Note that the screw in the position (D) does not need to be removed.
D
è
Cover
5. Remove the connector, and then remove the battery.
Connector
Battery
To Next Page
