Getting Started
4
Description of Parts
D
E
F
G
A
I
J
K
L
M
N
O
P
Q
R
B
C
H
F
A: Speaker
B: Function Keys
è
Reference Manual “Key Combinations”
C: Keyboard
D: Windows Button
E: Camera
è
Reference Manual “Camera”
F: Microphone
G: Camera Indicator
H: Ambient Light Sensor
The ambient light sensor is equipped
with an automatic brightness adjustment
function that adjusts the display screen.
I: LCD (with touchscreen)
è
Reference Manual “Screen Input Operation”
J: Strap Holder (Both sides)
Mounting holder for a hand strap (optional).
K: DC-IN Jack
L: VGA Port
è
Reference Manual “External Display”
M: LAN Port
è Reference Manual “LAN
”
N: HDMI Port
è
Reference Manual “External Display
”
O: USB 3.0 Port
USB 3.0 Port (USB Charging)
è Reference Manual “USB Devices
”
•
Keep USB memory cards away from
infants and small children.
•
Do not insert any foreign object in the
USB port.
P: Microphone Jack
A condenser microphone can be used.
If other types of microphones are used,
audio input may not be possible, or
malfunctions may occur as a result.
Q: Headphone Jack
You can connect headphones or amplified
speakers. When they are connected, audio
from the internal speakers is not heard.
R: Wireless Switch
WIRELESS
è
Reference Manual “Disabling/
Enabling Wireless Communication
”
