Appendix
37
■ Main Specifications
Camera Resolution FHD 1080p
Effective number
of pixels
Max. 1920 x 1080
Microphone Built-in (Microphone Array)
Ambient light sensor Equipped
Magnetic sensor Equipped
Gyro sensor Equipped
Acceleration sensor Equipped
Power Supply AC adaptor or Battery pack
AC Adaptor
*12
Input: 100 V - 240 V AC, 50 Hz/60 Hz, Output: 16 V DC, 4.06 A
Built-in Battery (not replaceable)
(For hot swap only)
Battery Pack Li-ion 7.2 V, Typical 4800 mAh / Minimum 4560 mAh
Operating Time
*13
<Model with 4 GB main memory>
Approx. 13 hours (Economy Mode (ECO) - Disable)
<Model with 8 GB main memory>
Approx. 12.5 hours (Economy Mode (ECO) - Disable)
Charging Time
*14
Approx. 4 hours
Remaining battery indicator
recalibration time
Full charge: Approx. 4 hours (max.)
Complete discharge: Approx. 5 hours (max.)
Battery
duration
*15
In sleep Approx. 8 days
(Approx. 6 days with Wake Up from wired LAN function activated)
In hibernation Approx. 35 days
(Approx. 10 days with Wake Up from wired LAN function activated)
When power is off Approx. 35 days
(Approx. 10 days with Power On by LAN function activated)
Power Consumption
*16
Approx. 20 W
*17
/ Approx. 45 W (maximum when recharging in the ON state)
Physical Dimensions (W × D × H)
301.4 mm × 210 mm × 21 mm
Weight Model without either wireless WAN or smart card slot: Approx. 1.140 kg
Model with wireless WAN, but without smart card slot: Approx. 1.145 kg
Model without wireless WAN, but with smart card slot: Approx. 1.155 kg
Model with wireless WAN and smart card slot: Approx. 1.160 kg
Environment
Operating
Temperature
5 °C to 35 °C
Humidity
30 % to 80 % RH (No condensation)
Storage Temperature
- 20 °C to 60 °C
Humidity
30 % to 90 % RH (No condensation)
