Panasonic CQ-JA1920L User Manual

Ref.
No.
Part No. Part Name & Description Remarks
D602 MA142WATX Diode
D603 YEAD1SS355T1 Diode
D605 MA151WATX Diode
D606 MA151WATX Diode
D607 YEAD1SS355T1 Diode
D609 B0BC5R600014 Diode
D610 YEAD1SS355T1 Diode
D611 YEADRD51M2T1 Diode
D612 YEAD1SS355T1 Diode
D613 YEAD1SS355T1 Diode
D614 YEAD1SS355T1 Diode
D615 YEADRD51M2T1 Diode
D616 YEADRD51M2T1 Diode
D621 YEAD1SS355T1 Diode
D622 MA2J72900L Diode
D623 YEADRD51M2T1 Diode
D624 MA151WATX Diode
D626 YEAD1SS355T1 Diode
D651 MA151WATX Diode
D684 MA142WATX Diode
D685 YEAD1SS355T1 Diode
D696 YEADRD51M2T1 Diode
D697 MA151WATX Diode
D698 YEADRD56M2T1 Diode
D699 YEAD1SS355T1 Diode
D700 YEADRB051L40 Diode
D702 YEAD1SS355T1 Diode
D703 MA142WKTX Diode
D704 YEADRD56M3T1 Diode
D710 YEAD1SS355T1 Diode
D711 YEAD1SS355T1 Diode
D722 YEADRD51M2T1 Diode
D725 YEAD1SS355T1 Diode
D730 MA741TX Diode
D731 MA151WKTX Diode
D732 YEAD1SS355T1 Diode
D733 MA142WATX Diode
D734 MA142WATX Diode
D735 MA741TX Diode
D771 YEADEC10DS1 Diode
D772 YEADEC10DS1 Diode
D773 MA159TX Diode
D780 MA3068MTX Diode
D782 YEADDSM3MA2T Diode
D801 MA151WKTX Diode
D802 YEADRD51M2T1 Diode
D803 YEADEC10DS1 Diode
D808 MA721TX Diode
D901 YEADRB051L40 Diode
D908 YEAD1SS355T1 Diode
D992 MA142WATX Diode
D993 YEAD1SS355T1 Diode
CAPACITORs
Ref.
No.
Part No. Part Name & Description Remarks
C48 YECUS1C474KX Ceramic, 0.47µF 16WV
C49 ECEA1CKA101 Electrolytic, 100µF 16WV
C50 YECUS1H101JM Ceramic, 100PF 50WV
C53 ECEA1CKA100I Electrolytic, 10µF 16WV
C54 ECEA1HKA010I Electrolytic, 1µF 50WV
C56 ECEA1CKA100I Electrolytic, 10µF 16WV
C102 YECUS1H102KX Ceramic, 0.001µF 50WV
C103 YECUS1H103KX Ceramic, 0.01µF 50WV
C104 ECA1AM101I Electrolytic, 100µF 10WV
C105 YECUS1E223KX Ceramic, 0.022µF 25WV
C106 YECUS1H153KX Ceramic, 0.015µF 50WV
C107 YECUS1C154KX Ceramic, 0.15µF 16WV
C108 YECUS1H103KX Ceramic, 0.01µF 50WV
C109 YECUS1H183KX Ceramic, 0.018µF 50WV
C110 YECUS1C154KX Ceramic, 0.15µF 16WV
C111 YECUS1H103KX Ceramic, 0.01µF 50WV
C112 ECEA1CKA100I Electrolytic, 10µF 16WV
C113 YECUS1H103KX Ceramic, 0.01µF 50WV
Ref.
No.
Part No. Part Name & Description Remarks
C114 YECUS1H102KX Ceramic, 0.001µF 50WV
C115 YECUS1H102KX Ceramic, 0.001µF 50WV
C116 YECUS1H101JM Ceramic, 100PF 50WV
C117 YECUS1H103KX Ceramic, 0.01µF 50WV
C118 YECUS1H101JM Ceramic, 100PF 50WV
C119 YECUS1E223KX Ceramic, 0.022µF 25WV
C120 YECUS1H103KX Ceramic, 0.01µF 50WV
C121 ECA1AM221I Electrolytic, 220µF 10WV
C124 YECUS1H101JM Ceramic, 100PF 50WV
C125 YECUZ1H271JC Ceramic, 270PF 50WV
C126 F1H1E103A011 Ceramic, 0.01µF 25WV
C127 F1H1E103A011 Ceramic, 0.01µF 25WV
C129 YECUS1H103KX Ceramic, 0.01µF 50WV
C130 YECUS1H820JM Ceramic, 82PF 50WV
C131 F1H1E103A011 Ceramic, 0.01µF 25WV
C152 YECUS1H122KX Ceramic, 0.0012µF 50WV
C153 YECUS1H152KX Ceramic, 0.0015µF 50WV
C154 YECUS1H103KX Ceramic, 0.01µF 50WV
C155 YECUS1H151JM Ceramic, 150PF 50WV
C156 YECUS1H151JM Ceramic, 150PF 50WV
C157 YECUS1H151JM Ceramic, 150PF 50WV
C158 YECUS1H102KX Ceramic, 0.001µF 50WV
C159 YECUS1H220JM Ceramic, 22PF 50WV
C160 YECUZ1H102KX Ceramic, 0.001µF 50WV
C161 YECUZ1E223KX Ceramic, 0.022µF 25WV
C163 ECEA1CKA100I Electrolytic, 10µF 16WV
C164 YECUS1H151JM Ceramic, 150PF 50WV
C169 F1J1C274A006 Ceramic, 0.27µF 16WV
C170 YECUS1H560JM Ceramic, 56PF 50WV
C171 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C172 YECUS1H271JM Ceramic, 270PF 50WV
C173 F1J1H121A034 Ceramic, 120PF 50WV
C174 YECUS1H220JM Ceramic, 22PF 50WV
C175 YECUS1H220JM Ceramic, 22PF 50WV
C176 ECEA0JKA470I Electrolytic, 47µF 6.3WV
C177 YECUS1C224KX Ceramic, 0.22µF 16WV
C178 ECEA0JKA470I Electrolytic, 47µF 6.3WV
C179 YECUS1C224KX Ceramic, 0.22µF 16WV
C201 ECEA1CKS100I Electrolytic, 10µF 16WV
C202 ECEA1CKS100I Electrolytic, 10µF 16WV
C203 ECA1HM2R2I Electrolytic, 2.2µF 50WV
C204 ECA1CM470I Electrolytic, 47µF 16WV
C207 YECUS1C104KX Ceramic, 0.1µF 16WV
C208 ECA1CM470I Electrolytic, 47µF 16WV
C211 YECUS1H123KX Ceramic, 0.012µF 50WV
C212 ECEA1CKS100I Electrolytic, 10µF 16WV
C213 YECUS1H470JM Ceramic, 47PF 50WV
C214 ECEA1CKN100I Electrolytic, 10µF 16WV
C216 YECUS1H153KX Ceramic, 0.015µF 50WV
C217 YECUS1H221JM Ceramic, 220PF 50WV
C218 YECUS1H101JM Ceramic, 100PF 50WV
C222 YECUS1C474KX Ceramic, 0.47µF 16WV
C228 ECEA1AKA220I Electrolytic, 22µF 10WV
C229 YECUS1H151JM Ceramic, 150PF 50WV
C230 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C231 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C234 YECUS1H151JM Ceramic, 150PF 50WV
C251 ECEA1CKA100I Electrolytic, 10µF 16WV
C252 ECA1HM2R2I Electrolytic, 2.2µF 50WV
C253 ECA1HM2R2I Electrolytic, 2.2µF 50WV
C254 ECA1HM2R2I Electrolytic, 2.2µF 50WV
C255 ECEA1CKA470I Electrolytic, 47µF 16WV
C256 ECEA1CKA470I Electrolytic, 47µF 16WV
C258 YECUS1H101JM Ceramic, 100PF 50WV
C259 YECUS1H101JM Ceramic, 100PF 50WV
C260 YECUZ1H271JC Ceramic, 270PF 50WV
C261 YECUS1H271JM Ceramic, 270PF 50WV
C263 YECUS1H272KX Ceramic, 0.0027µF 50WV
C264 YECUZ1H272KX Ceramic, 0.0027µF 50WV
C271 YECUS1H221JC Ceramic, 220PF 50WV
C272 YECUS1H221JC Ceramic, 220PF 50WV
C273 YECUS1H103KX Ceramic, 0.01µF 50WV
C274 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
17
AUDI / CQ-JA1920L / CQ-JA1924L
