11 REPLACEMENT PARTS
LIST
Notes :
1. Be sure to make your orders of replacement parts
according to this list.
2. Important safety notice: Components, identified by
mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3. Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4. The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
5. "MCC" marks in remarks column are indicated supply parts
of Matsushita Communication Industrial Corp. of America
(MCC).
11.1. Main/Amp/DSP/Connector
Block [E6791]
IC´s and TRANSISTORs
Ref.
No.
Part No. Part Name & Description Remarks
IC101 AN6564NST1 IC
IC151 C0ABCB000005 IC
IC171 YEAMBU1923F IC
IC233 C0ABCB000005 IC
IC262 YEAMTC4W53FT IC
IC263 C0ABCB000005 IC
IC265 YEAMPC4570T1 IC
IC267 C0JBAR000066 IC
IC268 C0ABCB000005 IC
IC281 AN7190NKLC IC
IC282 YEAMCX2510AQ IC
IC335 C0ABCB000005 IC
IC501 YEAMS6789A IC
IC502 YEAMS6684B IC
IC601 C0EBM0000005 IC
IC602 YEAMS2922ADF IC
IC603 AN8065SE1 IC
IC606 YEAMC14584BE IC
IC607 C0CBABA00006 IC
IC621 C2CBKJ000009 IC
IC625 YEAMNJU7660M IC
IC626 C0ABBA000022 IC
IC627 C0ABBA000022 IC
IC635 C0JBAB000178 IC
IC701 YEAMLC72146T IC
IC703 C0DBZHZ00005 IC
IC711 YEAMLB1930MT IC
IC751 AN7805 IC
IC781 YEAMPC4570T1 IC
IC801 YEAMAK7712AF IC
IC802 AN7805 IC
IC803 AN7805 IC
IC901 C2BBGD000067 IC
IC902 C1EB00000036 IC
PA101 YEP0PTA533B0 Tuner Pack
Q53 2SB1073TX Transistor
Q54 YEANC114EUKT Transistor
Ref.
No.
Part No. Part Name & Description Remarks
Q55 B1BBAC000007 Transistor
Q101 B1GBCFNN0005 Transistor
Q120 B1ABBD000004 Transistor
Q202 YEANC3661TA Transistor
Q222 YEANC323TUTX Transistor
Q253 YEANC323TKT Transistor
Q254 YEANC323TKT Transistor
Q287 YEANC114YUTX Transistor
Q302 YEANC3661TA Transistor
Q303 YEANC4081STX Transistor
Q322 YEANC323TUTX Transistor
Q353 YEANC323TKT Transistor
Q354 YEANC323TKT Transistor
Q393 YEANC144EUTX Transistor
Q394 YEANC144EUTX Transistor
Q395 YEANC144EUTX Transistor
Q501 YEANA114EUKT Transistor
Q502 YEANC114YUTX Transistor
Q511 YEANA114EUKT Transistor
Q512 YEANC144EUTX Transistor
Q600 YEANC4081STX Transistor
Q603 YEANFP1F3PT1 Transistor
Q608 B1BBAC000007 Transistor
Q621 B1ADJC000003 Transistor
Q622 YEANC144EUTX Transistor
Q627 B1GBCFJN0005 Transistor
Q671 YEANC4081STX Transistor
Q672 YEANA144EKTX Transistor
Q673 YEANC114EUKT Transistor
Q681 YEANC114YUTX Transistor
Q682 YEANFP1F3PT1 Transistor
Q689 B1ABCF000042 Transistor
Q701 YEAN2SK536TB Transistor
Q702 2SB1398QTA Transistor
Q703 YEANA114YKTX Transistor
Q705 YEAN2SA1757 Transistor
Q706 B1BBAC000007 Transistor
Q708 B1GBCFJN0005 Transistor
Q709 YEANFP1F3PT1 Transistor
Q710 YEANFP1F3PT1 Transistor
Q711 B1ADNC000001 Transistor
Q712 B1BBAC000007 Transistor
Q713 2SD1328STTX Transistor
Q723 B1ADJC000003 Transistor
Q724 YEANC114YUTX Transistor
Q725 YEANA114YKTX Transistor
Q729 YEANA114EUKT Transistor
Q730 YEANA114EUKT Transistor
Q731 YEANC114EUKT Transistor
Q773 YEANC323TKT Transistor
Q774 YEANC323TKT Transistor
Q775 B1ABCF000044 Transistor
Q776 B1ABCF000044 Transistor
Q801 B1ABCF000044 Transistor
Q802 YEANHR1F3PT1 Transistor
Q803 YEANC114EUKT Transistor
Q901 YEANC4081STX Transistor
Q902 YEANC4081STX Transistor
Q903 B1ABCF000042 Transistor
Q904 YEANA144EKTX Transistor
Q905 YEANA144EKTX Transistor
Q906 YEANC3661TA Transistor
DIODEs
Ref.
No.
Part No. Part Name & Description Remarks
D51 YEADRD10M2T1 Diode
D52 YEADRD43M2T2 Diode
D55 MA151WKTX Diode
D151 MA153TX Diode
D152 MA153TX Diode
D156 MA151WKTX Diode
D600 YEAD1SS355T1 Diode
D601 MA142WATX Diode
16
AUDI / CQ-JA1920L / CQ-JA1924L
