Panasonic CQ-JA1920L User Manual

13.1. CD Servo Block [E8550]
IC´s and TRANSISTORs
Ref.
No.
Part No. Part Name & Description Remarks
IC101 YEAMCXA2535 IC
IC401 YEAMCXD2597Q IC
IC451 C2BBFC000021 IC
IC901 YEAMBA6195FP IC
IC951 YEAMBA5971FP IC
Q101 2SB766ATX Transistor
DIODEs
Ref.
No.
Part No. Part Name & Description Remarks
D402 MA151ATX Diode
D451 MA151WKTX Diode
PS1 0N1004 Diode
PS3 0N1004 Diode
CAPACITORs
Ref.
No.
Part No. Part Name & Description Remarks
C101 YECUS1C104KX Ceramic, 0.1µF 16WV
C102 YECUS1C104KX Ceramic, 0.1µF 16WV
C103 YECUS1C104KX Ceramic, 0.1µF 16WV
C104 F3H0J1070005 Tantalum, 100µF 6.3WV
C105 YECUS1C104KX Ceramic, 0.1µF 16WV
C106 YECUS1C224KX Ceramic, 0.22µF 16WV
C107 F1K1H121A027 Ceramic, 120PF 50WV
C108 YECUS1H330JM Ceramic, 33PF 50WV
C109 YECUS1H390JM Ceramic, 39PF 50WV
C110 YECUS1H222KX Ceramic, 0.0022µF 50WV
C111 YECUS1H102KX Ceramic, 0.001µF 50WV
C112 YECUS1C104KX Ceramic, 0.1µF 16WV
C113 YECUS1C104KX Ceramic, 0.1µF 16WV
C114 YECUV1H331JM Ceramic, 330PF 50WV
C115 YECUS1C104KX Ceramic, 0.1µF 16WV
C116 ECEH0JVC470F Electrolytic, 47µF 6.3WV
C118 ECEH0JVC470F Electrolytic, 47µF 6.3wv
C119 F1J1H3R0A007 Ceramic, 3PF 50WV
C401 YECUV2A103KX Ceramic, 0.01µF 100WV
C402 YECUV1C474KX Ceramic, 0.47µF 16WV
C403 YECUS1H221JM Ceramic, 220PF 50WV
C404 YECUS1H152KX Ceramic, 0.0015µF 50WV
C405 YECUS1C104KX Ceramic, 0.1µF 16WV
C406 ECEH0JVC470F Electrolytic, 47µF 6.3WV
C407 YECUS1C104KX Ceramic, 0.1µF 16WV
C408 ECEH0JVC470F Electrolytic, 47µF 6.3WV
C409 YECUS1C104KX Ceramic, 0.1µF 16WV
C410 ECEH0JV101F Electrolytic, 100µF 6.3WV
C411 YECUS1C104KX Ceramic, 0.1µF 16WV
C412 YECUS1C104KX Ceramic, 0.1µF 16WV
C413 YECUS1C104KX Ceramic, 0.1µF 16WV
C414 YECUS1C104KX Ceramic, 0.1µF 16WV
C415 YECUS1H473KX Ceramic, 0.047µF 50WV
C416 YECUS1C104KX Ceramic, 0.1µF 16WV
C453 YECUS1C104KX Ceramic, 0.1µF 16WV
C454 ECEH0JVC470F Electrolytic, 47µF 6.3WV
C455 YECUS1H103KX Ceramic, 0.01µF 50WV
C901 YECUS1E393KX Ceramic, 0.039µF 25WV
C902 YECUS1C104KX Ceramic, 0.1µF 16WV
C903 ECEH1CVC220F Electrolytic, 22µF 16WV
C904 YECUS1C104KX Ceramic, 0.1µF 16WV
C951 YECUS1H222KX Ceramic, 0.0022µF 50WV
C952 YECUV2A222KX Ceramic, 0.0022µF 100WV
C953 YECUS1H222KX Ceramic, 0.0022µF 50WV
C954 YECUS1H222KX Ceramic, 0.0022µF 50WV
C955 ECEH1CVC220F Electrolytic, 22µF 16WV
C956 YECUS1C104KX Ceramic, 0.1µF 16WV
C957 YECUV1C104KX Ceramic, 0.1µF 16WV
C958 YECUS1E333KX Ceramic, 0.033µF 25WV
C959 YECUS1E333KX Ceramic, 0.033µF 25WV
RESISTORs
Ref.
No.
Part No. Part Name & Description Remarks
R101 ERJ8GEYJ273V Chip, 27k
Ω
ΩΩ
Ω
1/8W
R102 ERJ8GEYJ273V Chip, 27k
Ω
ΩΩ
Ω
1/8W
R103 ERJ12YJ330H Chip, 33
Ω
ΩΩ
Ω
1/2W
R104 ERJ8GEYJ273V Chip, 27k
Ω
ΩΩ
Ω
1/8W
R105 ERJ8GEYJ273V Chip, 27k
Ω
ΩΩ
Ω
1/8W
R106 ERJ8GEYJ333V Chip, 33k
Ω
ΩΩ
Ω
1/8W
R107 ERJ8GEYJ333V Chip, 33k
Ω
ΩΩ
Ω
1/8W
R108 ERJ6GEYJ334 Chip, 330k
Ω
ΩΩ
Ω
1/10W
R109 ERJ8GEYJ103V Chip, 10k
Ω
ΩΩ
Ω
1/8W
R110 ERJ8GEYJ223V Chip, 22k
Ω
ΩΩ
Ω
1/8W
R111 ERJ6GEYJ272 Chip, 2.7k
Ω
ΩΩ
Ω
1/10W
R112 ERJ6GEYJ101 Chip, 100
Ω
ΩΩ
Ω
1/10W
R113 ERJ8GEYJ124V Chip, 120k
Ω
ΩΩ
Ω
1/8W
R115 ERJ8GEYJ103V Chip, 10k
Ω
ΩΩ
Ω
1/8W
R116 ERJ6GEYJ101 Chip, 100
Ω
ΩΩ
Ω
1/10W
R117 ERJ8GEYJ152V Chip, 1.5k
Ω
ΩΩ
Ω
1/8W
R401 ERJ8GEYJ102V Chip, 1k
Ω
ΩΩ
Ω
1/8W
R402 ERJ8GEYJ472V Chip, 4.7k
Ω
ΩΩ
Ω
1/8W
R403 ERJ8GEYJ472V Chip, 4.7k
Ω
ΩΩ
Ω
1/8W
R404 ERJ8GEYJ472V Chip, 4.7k
Ω
ΩΩ
Ω
1/8W
R405 ERJ8GEYJ472V Chip, 4.7k
Ω
ΩΩ
Ω
1/8W
R406 ERJ8GEYJ472V Chip, 4.7k
Ω
ΩΩ
Ω
1/8W
R407 ERJ6GEYJ333 Chip, 33k
Ω
ΩΩ
Ω
1/10W
R408 ERJ6GEYJ103 Chip, 10k
Ω
ΩΩ
Ω
1/10W
R409 ERJ6GEYJ104 Chip, 100k
Ω
ΩΩ
Ω
1/10W
R410 ERJ6GEYJ394 Chip, 390k
Ω
ΩΩ
Ω
1/10W
R411 ERJ6GEYJ103 Chip, 10k
Ω
ΩΩ
Ω
1/10W
R412 ERJ6GEYJ332 Chip, 3.3k
Ω
ΩΩ
Ω
1/10W
R413 ERJ6GEYJ332 Chip, 3.3k
Ω
ΩΩ
Ω
1/10W
R415 ERJ6GEYJ334 Chip, 330k
Ω
ΩΩ
Ω
1/10W
R416 ERJ6GEYJ564 Chip, 560k
Ω
ΩΩ
Ω
1/10W
R417 ERJ6GEYJ105 Chip, 1M
Ω
ΩΩ
Ω
1/10W
R451 ERJ6GEYJ221 Chip, 220
Ω
ΩΩ
Ω
1/10W
R453 ERJ8GEYJ472V Chip, 4.7k
Ω
ΩΩ
Ω
1/8W
R454 ERJ6GEYJ473 Chip, 47k
Ω
ΩΩ
Ω
1/10W
R455 ERJ8GEYJ473V Chip, 47k
Ω
ΩΩ
Ω
1/8W
R456 ERJ8GEYJ472V Chip, 4.7k
Ω
ΩΩ
Ω
1/8W
R457 ERJ8GEYJ473V Chip, 47k
Ω
ΩΩ
Ω
1/8W
R458 ERJ6GEYJ563 Chip, 56k
Ω
ΩΩ
Ω
1/10W
R459 ERJ8GEYJ563V Chip, 56k
Ω
ΩΩ
Ω
1/8W
R460 ERJ8GEYJ472V Chip, 4.7k
Ω
ΩΩ
Ω
1/8W
R901 ERJ8GEYJ223V Chip, 22k
Ω
ΩΩ
Ω
1/8W
R902 ERJ6GEYJ103 Chip, 10k
Ω
ΩΩ
Ω
1/10W
R903 ERJ8GEYJ392V Chip, 3.9k
Ω
ΩΩ
Ω
1/8W
R904 ERJ8GEYJ682V Chip, 6.8k
Ω
ΩΩ
Ω
1/8W
R905 ERJ6GEYJ103 Chip, 10k
Ω
ΩΩ
Ω
1/10W
R951 ERJ8GEYJ223V Chip, 22k
Ω
ΩΩ
Ω
1/8W
R952 ERJ8GEYJ223V Chip, 22k
Ω
ΩΩ
Ω
1/8W
R953 ERJ8GEYJ223V Chip, 22k
Ω
ΩΩ
Ω
1/8W
R954 ERJ8GEYJ223V Chip, 22k
Ω
ΩΩ
Ω
1/8W
R955 ERJ6GEYJ562 Chip, 5.6k
Ω
ΩΩ
Ω
1/10W
R956 ERJ8GEYJ562V Chip, 5.6k
Ω
ΩΩ
Ω
1/8W
R957 ERJ6GEYJ562 Chip, 5.6k
Ω
ΩΩ
Ω
1/10W
R958 ERJ6GEYJ562 Chip, 5.6k
Ω
ΩΩ
Ω
1/10W
R959 ERJ8GEYJ223V Chip, 22k
Ω
ΩΩ
Ω
1/8W
R960 ERJ8GEYJ223V Chip, 22k
Ω
ΩΩ
Ω
1/8W
R961 ERJ6GEYJ562 Chip, 5.6k
Ω
ΩΩ
Ω
1/10W
R962 ERJ6GEYJ562 Chip, 5.6k
Ω
ΩΩ
Ω
1/10W
R964 ERJ8GEYJ472V Chip, 4.7k
Ω
ΩΩ
Ω
1/8W
R965 ERJ8GEYJ472V Chip, 4.7k
Ω
ΩΩ
Ω
1/8W
CONNECTORs
Ref.
No.
Part No. Part Name & Description Remarks
CN101 YEAE5220715 Connector, 15P
CN401 YEAE0114TKCR Connector, 14P
CN901 YEAE5227106 Connector, 6P
CN902 YEAE5326102 Connector, 2P
13 CD PLAYER PARTS
26
AUDI / CQ-JA1920L / CQ-JA1924L
