Panasonic CQ-JA1920L User Manual

SWITCHEs
Ref.
No.
Part No. Part Name & Description Remarks
SW2 YEAS09248R Push Switch
AS1 YEAS23151A Leef Switch
CRYSTALs
Ref.
No.
Part No. Part Name & Description Remarks
XL401 YEXLCSTC169T Crystal OSC
XL451 YEXLSTCC419T Crystal OSC
COIL
Ref.
No.
Part No. Part Name & Description Remarks
L101 YELTLM41P750 Coil
13.2. Miscellaneous
Ref.
No.
Part No. Part Name & Description Remarks
YEP0PT8550A1 PCB w/Component
TP1 YEATSD00405 Bracket
1 YEFX018497A PCB Holder
2 YEFX003732A Clamper Gear(1)
3 YEFX003733 Clamper Gear(2)
4 YEFX003741B Loding Gear(1)
5 YEFX003742B Loding Gear(2)
6 YEFX0051986 Feeder Arm Spring(1)
7 YEFA011537K Front Chassis
8 YEFX003842 Clamper Gear(3)
9 YEP0FX2519 Loding Motor Ass´y
10 YEFX0461879A Joint Lever Ass´y
11 YEFX0051997B Loding Motor Spring
12 YEFX018435 Dumper Bracket
13 YEFX0051988C Switch Lever Spring
14 YEFX0461662B OUT Switch Lever
15 YEFX0461660A IN Switch Lever
16 YEFS04692 Dumper(B)
16-1 YEFS04625 Dumper(A)
17 YEFX0052000B Clamper Arm Spring
18 YEFX0461883A Clamper Lever Ass´y
19 YEFX0052107 Suspension Spring
20 YEFX0051996 Suspension Spring
21 YEAP2509A Flat Cable
22 YEFX9991458A FPC Holder
24 YEFW04150 Shaft Holder(A)
25 YEFX0051998 Change Lever(A) Spring
26 YEFX0461876A Change Lever(A) Ass´y
27 YEFX0461661C Load Switch Lever
28 YEP0FX3498 Spindle Motor Ass´y
29 YEFX9991406B Feed Screw Holder
30 YEJT03211 Feed Screw Ass´y
31 YEFW04137A Shaft Holder(B)
32 YEFX0051992 Thrust Adjustment Spring
33 YESFD13005 Optical Pick-up Ass´y
34 YEFX234179B Clamper Cam
35 YEP0FX3472 Traverse Motor Ass´y
36 YEFR03080 Belt
37 YEFX236144A Traverse Guide
38 YEFA011733 Suspension Chassis
39 YEFX0051991C Side PressureSpring
40 YEFS011325 Pad
41 YEP0FX2522 Clamper Unit
42 YEFX0051590 Vibration Spring
44 YEFX003735B Clamper Rack
45 YEFX0461880 Fook
46 YEFX0051987 Clamper Rack Spring
47 YEFX0461658A Feeder Lever
48 YEFX0461654A Lock Lever(L)
50 YEP0FX2526 Roller Gear Ass´y
51 YEFX218282 Rubber Roller
52 YEFX003762 Roller Gear(4)
53 YEFX003731A Loding Gear(3)
54 YEFX0461846 Feeder Arm Ass´y
55 YEFW04144 Shaft Holder(1)
Ref.
No.
Part No. Part Name & Description Remarks
56 YEFX249408C Lever Protection Cover
57 YEFW04138 Shaft Holder(2)
58 YEFX0052059 Feeder Arm Spring(2)
60 YEFX0461668E Detect Lever(R)
61 YEFX0052032 Lever Spring
62 YEFX249407A Lock Control Plate
64 YEFX0461655A Lock Lever(R) Ass´y
65 YEFX9991635 Lock Lever(L)
66 YEFX236145E Disc Guide
67 YEFX0461671B Detect Arm(R)
68 YEFX0051994 Lever Spring(A)
69 YEFX0461669E Detect Lever(L)
70 YEFX0461672B Detect Arm(L)
71 YEFX0051995 Lever Spring(B)
72 YEFX0461772 Slide Plate
73 YEFA011606 Main Chassis
80 XUC15V Retaining Ring, 1.5mm
81 XUC2V Retaining Ring, 2mm
82 YEJE01004 Retaining Ring, 2mm
83 YEJW04128 Washer
84 YEJS06097A Screw, 2mm * 2.5mm
86 YEJS02018FZ Screw, 1.6mm * 7mm
87 YEJT03152 Tapping Screw
88 YEJT03132 Tapping Screw, 2.6mm * 4mm
89 YEJT03131 Tapping Screw, 2.6 * 5mm
90 YEJT03180 Tapping Screw, 2.6mm * 6mm
91 XQN17+A25FX Screw
92 XYN2+J10FX Screw
93 XYN2+C5FX Screw, 2mm * 5mm
94 YEJS06187 Screw, 2mm * 2.5mm
95 YEJS02037 Screw, 1.7mm * 2.5mm
