Panasonic CQ-JA1920L User Manual

Ref.
No.
Part No. Part Name & Description Remarks
C734 ECA1AM101I Electrolytic, 100µF 10WV
C735 YECUS1H101JM Ceramic, 100PF 50WV
C736 YECUS1H101JM Ceramic, 100PF 50WV
C737 YECUS1H103KX Ceramic, 0.01µF 50WV
C738 ECA1CM100I Electrolytic, 10µF 16WV
C739 YECUS1C104KX Ceramic, 0.1µF 16WV
C740 YECUS1C104KX Ceramic, 0.1µF 16WV
C742 YECUZ1C104KX Ceramic, 0.1µF 16WV
C749 YECUS1C474KX Ceramic, 0.47µF 16WV
C751 ECEA0JKA221I Electrolytic, 220µF 6.3WV
C752 YECUV1C224KX Ceramic, 0.22µF 16WV
C756 ECEA1CKA100I Electrolytic, 10µF 16WV
C771 ECA1HM2R2I Electrolytic, 2.2µF 50WV
C772 ECA1HM2R2I Electrolytic, 2.2µF 50WV
C773 F1K1C474A014 Ceramic, 0.47µF 16WV
C774 F1K1C474A014 Ceramic, 0.47µF 16WV
C775 F1K1C474A014 Ceramic, 0.47µF 16WV
C776 F1K1C474A014 Ceramic, 0.47µF 16WV
C781 ECA1CM102B Electrolytic, 1000µF 16WV
C782 YECUS1H103KX Ceramic, 0.01µF 50WV
C783 YECUS1H103KX Ceramic, 0.01µF 50WV
C784 ECA1CM102B Electrolytic, 1000µF 16WV
C785 YECUS1E223KX Ceramic, 0.022µF 25WV
C787 YECUS1C474KX Ceramic, 0.47µF 16WV
C788 YECUS1H101JM Ceramic, 100PF 50WV
C789 YECUS1H101JM Ceramic, 100PF 50WV
C790 ECA1CM470I Electrolytic, 47µF 16WV
C791 YECUS1C224ZF Ceramic, 0.22µF 16WV
C792 YECUS1C224ZF Ceramic, 0.22µF 16WV
C797 ECEA1AKA101I Electrolytic, 100µF 10WV
C798 F4D554730015 Tantalum, 0.047µF 5.5WV
C799 F4D554730015 Tantalum, 0.047µF 5.5WV
C801 YECUS1C104KX Ceramic, 0.1µF 16WV
C802 YECUS1C104KX Ceramic, 0.1µF 16WV
C803 ECEA1CKA100I Electrolytic, 10µF 16WV
C804 YECUS1C334KX Ceramic, 0.33µF 16WV
C805 YECUS1C334KX Ceramic, 0.33µF 16WV
C806 YECUS1C104KX Ceramic, 0.1µF 16WV
C807 YECUS1C104KX Ceramic, 0.1µF 16WV
C808 YECUS1C104KX Ceramic, 0.1µF 16WV
C809 YECUS1C104KX Ceramic, 0.1µF 16WV
C810 ECA1CM471B Electrolytic, 470µF 16WV
C811 F1K1A1060001 Ceramic, 10µF 10WV
C812 YECUS1C104KX Ceramic, 0.1µF 16WV
C813 ECEA1CKS100I Electrolytic, 10µF 16WV
C814 YECUS1C104KX Ceramic, 0.1µF 16WV
C815 YECUS1C104KX Ceramic, 0.1µF 16WV
C816 F1K1A1060001 Ceramic, 10µF 10WV
C817 YECUS1C334KX Ceramic, 0.33µF 16WV
C818 ECEA0JKA470I Electrolytic, 47µF 6.3WV
C819 YECUS1H180JC Ceramic, 18PF 50WV
C820 YECUS1H150JC Ceramic, 15PF 50WV
C821 YECUS1C104KX Ceramic, 0.1µF 16WV
C823 F1K1A1060001 Ceramic, 10µF 10WV
C826 YECUS1H332KX Ceramic, 0.0033µF 50WV
C827 YECUS1H332KX Ceramic, 0.0033µF 50WV
C828 ECEA1CKS100I Electrolytic, 10µF 16WV
C831 YECUS1H101JM Ceramic, 100PF 50WV
C832 YECUS1H101JM Ceramic, 100PF 50WV
C833 YECUS1H101JM Ceramic, 100PF 50WV
C834 YECUS1H101JM Ceramic, 100PF 50WV
C835 YECUS1H101JM Ceramic, 100PF 50WV
C901 F1J1H8R0A007 Ceramic, 8PF 50WV
C902 F1J1H8R0A007 Ceramic, 8PF 50WV
C903 YECUS1C104KX Ceramic, 0.1µF 16WV
C904 YECUS1C104KX Ceramic, 0.1µF 16WV
C906 YECUS1H101JM Ceramic, 100PF 50WV
C907 YECUS1C104KX Ceramic, 0.1µF 16WV
C908 YECUS1C104KX Ceramic, 0.1µF 16WV
C909 YECUS1C104KX Ceramic, 0.1µF 16WV
C910 YECUS1H101JM Ceramic, 100PF 50WV
C914 YECUS1H101JM Ceramic, 100PF 50WV
C915 YECUS1H101JM Ceramic, 100PF 50WV
Ref.
No.
Part No. Part Name & Description Remarks
C916 YECUS1H101JM Ceramic, 100PF 50WV
C917 YECUS1H101JM Ceramic, 100PF 50WV
C918 YECUS1H101JM Ceramic, 100PF 50WV
C934 YECUS1H331JM Ceramic, 330PF 50WV
C935 YECUS1H331JM Ceramic, 330PF 50WV
C991 YECUS1H103KX Ceramic, 0.01µF 50WV
C992 YECUS1H103KX Ceramic, 0.01µF 50WV
C993 YECUS1H103KX Ceramic, 0.01µF 50WV
C994 YECUS1H103KX Ceramic, 0.01µF 50WV
C995 YECUS1H103KX Ceramic, 0.01µF 50WV
RESISTORs
Ref.
No.
Part No. Part Name & Description Remarks
L102 ERJ8GEY0R00V Chip, 0
Ω
ΩΩ
Ω
1/8W
L171 ERJ6GEY0R00V Chip, 0
Ω
ΩΩ
Ω
1/10W
L602 ERJ6GEY0R00V Chip, 0
Ω
ΩΩ
Ω
1/10W
L610 ERJ6GEY0R00V Chip, 0
Ω
ΩΩ
Ω
1/10W
L614 ERJ6GEY0R00V Chip, 0
Ω
ΩΩ
Ω
1/10W
L625 ERJ6GEY0R00V Chip, 0
Ω
ΩΩ
Ω
1/10W
L626 ERJ6GEY0R00V Chip, 0
Ω
ΩΩ
Ω
1/10W
L702 ERJ6GEY0R00V Chip, 0
Ω
ΩΩ
Ω
1/10W
L821 ERJ6GEY0R00V Chip, 0
Ω
ΩΩ
Ω
1/10W
L822 ERJ6GEY0R00V Chip, 0
Ω
ΩΩ
Ω
1/10W
L909 ERJ6GEY0R00V Chip, 0
Ω
ΩΩ
Ω
1/10W
R53 ERJ6GEYJ2R2 Chip, 2.2
Ω
ΩΩ
Ω
1/10W
R54 ERJ6GEYJ153 Chip, 15k
Ω
ΩΩ
Ω
1/10W
R55 ERJ12YJ102H Chip, 1k
Ω
ΩΩ
Ω
1/2W
R56 ERJ6GEYJ473 Chip, 47k
Ω
ΩΩ
Ω
1/10W
R58 ERJ12YJ1R0H Chip, 1
Ω
ΩΩ
Ω
1/2W
R100 ERJ6GEY0R00 Chip, 0
Ω
ΩΩ
Ω
1/10W
R101 ERJ6GEYJ392 Chip, 3.9k
Ω
ΩΩ
Ω
1/10W
R102 ERJ6GEYJ334 Chip, 330k
Ω
ΩΩ
Ω
1/10W
R103 ERJ6GEYJ153 Chip, 15k
Ω
ΩΩ
Ω
1/10W
R104 ERJ6GEYJ183 Chip, 18k
Ω
ΩΩ
Ω
1/10W
R105 ERJ6GEYJ123 Chip, 12k
Ω
ΩΩ
Ω
1/10W
R106 ERJ6GEYJ472 Chip, 4.7k
Ω
ΩΩ
Ω
1/10W
R107 ERJ6GEYJ104 Chip, 100k
Ω
ΩΩ
Ω
1/10W
R108 ERJ6GEYJ223 Chip, 22k
Ω
ΩΩ
Ω
1/10W
R109 ERJ6GEYJ223 Chip, 22k
Ω
ΩΩ
Ω
1/10W
R110 ERJ6GEY0R00 Chip, 0
Ω
ΩΩ
Ω
1/10W
R111 ERJ6GEYJ563 Chip, 56k
Ω
ΩΩ
Ω
1/10W
R112 ERJ6GEYJ563 Chip, 56k
Ω
ΩΩ
Ω
1/10W
R113 ERJ6GEYJ101 Chip, 100
Ω
ΩΩ
Ω
1/10W
R114 ERJ6GEYJ682 Chip, 6.8k
Ω
ΩΩ
Ω
1/10W
R115 ERJ6GEYJ473 Chip, 47k
Ω
ΩΩ
Ω
1/10W
R116 ERJ6GEYJ104 Chip, 100k
Ω
ΩΩ
Ω
1/10W
R118 ERJ3GEYJ183V Chip, 18k
Ω
ΩΩ
Ω
1/16W
R119 ERJ6GEYJ102 Chip, 1k
Ω
ΩΩ
Ω
1/10W
R120 ERJ3GEYJ561V Chip, 560k
Ω
ΩΩ
Ω
1/16W
R122 ERJ3GEYJ223V Chip, 22k
Ω
ΩΩ
Ω
1/16W
R123 ERJ3GEYJ681V Chip, 680
Ω
ΩΩ
Ω
1/16W
R124 ERJ3GEYJ183V Chip, 18k
Ω
ΩΩ
Ω
1/16W
R125 ERJ3GEYJ183V Chip, 18k
Ω
ΩΩ
Ω
1/16W
R126 ERG1SJ271E Metal Oxid, 270
Ω
ΩΩ
Ω
1W
R127 ERG1SJ271E Metal Oxid, 270
Ω
ΩΩ
Ω
1W
R128 ERG1SJ271E Metal Oxid, 270
Ω
ΩΩ
Ω
1W
R153 ERJ6GEYJ222 Chip, 2.2k
Ω
ΩΩ
Ω
1/10W
R154 ERJ6GEYJ561 Chip, 560
Ω
ΩΩ
Ω
1/10W
R155 ERJ6GEYJ683 Chip, 68k
Ω
ΩΩ
Ω
1/10W
R156 ERJ6GEYJ332 Chip, 3.3k
Ω
ΩΩ
Ω
1/10W
R157 ERJ6GEYJ183 Chip, 18k
Ω
ΩΩ
Ω
1/10W
R158 ERJ6GEYJ102 Chip, 1k
Ω
ΩΩ
Ω
1/10W
R159 ERJ6GEYJ393 Chip, 39k
Ω
ΩΩ
Ω
1/10W
R160 ERJ6GEYJ103 Chip, 10k
Ω
ΩΩ
Ω
1/10W
R161 ERJ6GEYJ103 Chip, 10k
Ω
ΩΩ
Ω
1/10W
R162 ERJ6GEYJ393 Chip, 39k
Ω
ΩΩ
Ω
1/10W
R163 ERJ6GEYJ393 Chip, 39k
Ω
ΩΩ
Ω
1/10W
R164 ERJ6GEYJ103 Chip, 10k
Ω
ΩΩ
Ω
1/10W
R165 ERJ6GEYJ102 Chip, 1k
Ω
ΩΩ
Ω
1/10W
R166 ERJ6GEYJ224 Chip, 220k
Ω
ΩΩ
Ω
1/10W
R167 ERJ3GEYJ103V Chip, 10k
Ω
ΩΩ
Ω
1/16W
R168 ERJ6GEYJ103 Chip, 10k
Ω
ΩΩ
Ω
1/10W
R169 ERJ6GEY0R00 Chip, 0
Ω
ΩΩ
Ω
1/10W
19
AUDI / CQ-JA1920L / CQ-JA1924L
