Panasonic CS-A181KE User Manual

– 10 –
MAC9512086C2
CS-A181KE
Refrigeration Cycle Diagram
CS/CU-A181K
CS/CU-A241K
Dimensions
CU-A181K / CU-A241K
7577.5
130130 540
663
685
330
370
56.3800
300
35
Air intake direction
Air outlet direction Slots (12 x 17) Four places
3-way valve at
liquid side
3-way valve at
gas side
22
106.5
100cm
10cm
10cm
Required space for installation
Anchor bolt pitch 330 x 540
Unit : mm
COOLING
HEATING
PROCESS
STRAINER
3-WAY VALVE
3-WAY VALVE
INDOOR UNIT OUTDOOR UNIT
HEAT EXCHANGER
(EVAPORATOR)
SENSOR
SENSOR
PIPE
TEMP.
CAPILLARY TUBE
CHECK VALVE
COMPRESSOR
OIL
SEPARATOR
HEAT EXCHANGER
(CONDENSER)
4-WAY
VALVE
ACCUMULATOR
(SUB)
TEMP.
PIPE
SENSOR
ONLY OIL
V
SENSOR
INTAKE
(AIR TEMP.)
INTAKE
AIR TEMP.
2-WAY VALVE
CU-A241K ONLY
TUBE
CAPILLARY TUBE
Untitled-8 6/21/00, 9:54 AM10
