Panasonic CS-A181KE User Manual

– 42 –
MAC9512086C2
CS-A181KE
<Model: CS-A181KE / CS-A241KE>
Replacement Parts List
DESCRIPTION & NAME
CHASSY COMPLETE
CHASSY BACK COVER
FAN MOTOR
CROSS FLOW FAN COMPLETE
SCREW – CROSS FLOW FAN
BEARING ASS’Y
EVAPORATOR
FLARE NUT (1/4")
FLARE NUT (1/2") OR (5/8")
DISCHARGE GRILLE COMPLETE
MOTOR – AIR SWING
TAP – DRAIN TRAY
VANE
CONTROL BOARD
TERMINAL BOARD COMPLETE
POWER SUPPLY CORD
SLIDE SWITCH
TRANSFORMER COMPLETE
ELECTRONIC CONTROLLER
RECEIVER COMPLETE
RECEIVER COMPLETE HOLDER
SENSOR COMPLETE
CONTROL BOARD TOP COVER
CONTROL BOARD FRONT COVER
REMOTE CONTROL COMPLETE
REMOTE CONTROL UPPER CASE
CONTROL PANEL
KNOB
KNOB
CONTACTOR
ELECTRONIC CONTROLLER
INDICATOR
REMOTE CONTROL LOWER CASE
COVER
FRONT GRILLE COMPLETE
INTAKE GRILLE COMPLETE
AIR FILTER (LEFT)
AIR FILTER (RIGHT)
SCREW – FRONT GRILLE
CAP – FRONT GRILLE
DRAIN HOSE
OPERATING INSTRUCTIONS
INSTALLATION INSTRUCTIONS
INSTALLATION PLATE
BAG COMPLETE – INSTALLATION SCREW
AIR PURIFYING FILTER COMPLETE
AIR PURIFYING FILTER
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
CS-A181KE
CWD50C369
CWD93956
CWA98274
CWH02C058
CWH4580304
CWH64K007
CWB30C222
CWH6002140
CWT25007 (1/2")
CWE20C574
CWA98267
CWH4612103
CWE24443
CWH10943
CWA28C584
CWA20C779
CWA04088
CWA40C246
CWA741178
CWA741287
CWD93957
CWA50C616
CWH13473
CWH13C314
CWA75C556
CWE15C241
CWE311064
CWE17196A
CWE17197A
CWA65036C
CWA74224
CWE39199
CWE15128A
CWB80040A
CWE11C971
CWE22C329
CWD00232
CWD00231
XTT4+16C
CWH52258
CWH85178
CWF561629
CWF61692
CWH36152
CWH82C194
CWD00C111
CWD00220
CS-A241KE
←
←
CWA98273
←
←
←
CWB30C210
←
CWT25004 (5/8")
←
←
←
←
←
CWA28C585
CWA20C780
←
←
CWA741182
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
REMARKS
t
t
t
t
t
t
t
t
t
t
t
t
t
QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
3
1
1
1
1
1
1
2
(Note) ● All parts are supplied from MACC, Malaysia (Vendor Code: 086).
● t marked parts are recommended to be kept in stock.
